Factory Supply Electric Mini Concrete Pump for sale

Product Overview

Description

Factory Supply Electric Mini Concrete Pump  for sale

Secondary structure casting machine deal exclusively with the secondary structure of the construction work, the problem of low efficiency of production. This machine is small in size, simple operation, reduce staff labor intensity and flexibly in the floor construction, reliable nearly lintel, post casting.

Feature:

1. Break type hydraulic workers are afraid to touch not operating problems.

2. Maintenance cost is low.

3. The movement is very convenient a person may move than hydraulic type.

4. The machine is only 5.5 KW power is very convenient in every floor to 18 to 25 KW

5. The machine is very small only 60 * 80 size ,Any small place can enter.

(formerly type hydraulic volume is too big a lot of places can't pass in and out)

6. The whole machine adopts modular design .

7. Delivery can be adjusted freely from 1 to 6 meters.

Main Parameter:

Voltage	220V/380V
Motor power	7.5kw
Conveying height	1-6m(customized)
Conveying flow	7m³/h
Hose inner diameter	90mm
Hose external diameter	100mm
Screw diameter	10cm
The riser diameter	110cm
Aggregate size	0-4cm
Weight	180kg
Dimension	1500*600*800mm
