Basic function | Range | Accuracy | ||
Ac Voltage | 4V/40V/400V/750V | ±(0.8%+5) | ||
Dc Voltage | 400mV/4V/40V/400V/1000V | ±(0.5%+3) | ||
Ac Current | 40mA/400mA/20A | ±(2.0%+5) | ||
Dc Current | 400uA/40mA/400mA/20A4mA/400mA/20A | ±(1.2%+8) | ||
Resistance(Ω) | 4000/4k/40k/400k/4M/40M | ±(1.0%+5) | ||
Capactance | 10nf-100mF | ±(2.5%+20) | ||
Frequency | 10Hz-10MHz | ±(0.1%+5) | ||
Temperature | -40℃-1000-℃ | ±(1.0%+5) | ||
Duty ratio | 0.1%-99.9% | ±(0.1%+5) | ||
Workingfrequency | 40Hz-400Hz | ±(0.1%+5) | ||
Special function | ||||
NCV | √ | |||
Diode Test | √ | |||
HFE Test | √ | |||
ContinuityTest | √ | |||
Low Power Dispay | √ | |||
Auto Power Off | √ | |||
Max Dispay | 4000 | |||
Data maintenance | √ | |||
LCD display - analogue bar full symbol double display | √ | |||
Back light | √ | |||
General Characteristic | ||||
Power Supply | ||||
Lcd Size | 61x32mm | |||
Meter Color | Gray+blue | |||
Meter Weight | 358g | |||
Meter Size | 183x87x36mm | |||
Standard Accessories | testlead/Manual | |||
Packing Quantity | 40Pcs | |||
uter Packing Size | 43x31.5x56.5cm | |||
Gross Weight | 19Kg | |||
