High Output 1 ton ice cube maker /big cube ice machine
US $1050-$3150
Tunnel Freezer Commercial Tunnel Blast Chiller Freezer Freezer Quick Freezing Machine
- Category: Refrigeration & Heat Exchange Equipment >>>
- Supplier: Guangzhou Icesource Co. Ltd.
Share on (1600537142364):
Product Overview
Description
Project Description
Design basis & Environmental Conditions
1.Design Basis
GB/T50072-2010 Cold Storage Design Specifications
SBJ17-2009 Design Specifications And Provisions for Outdoor Assembly Cold Storage
JB/T9061-1999 Combined Cold Storage
GB50316-2000 (2008 version) Specification for Design of Industrial Metal Piping
GB50052-2009 Design Specification for Power Supply and Distribution System
2.Environmental Conditions
Summer Outdoor Temperature, Average Annual Temperature 20.2℃
Highest Temperature, 38.5℃
Relative Humidity, ≤90%
Ambient temperature cooling in summer. The ambient temperature can be set as the summer standard: it belongs to the south subtropical type (T) 1.5---38.5℃, the cooling parameters are designed according to the subtropical average 32℃ environment, and the summer refrigeration unit can be adopted in winter.
Summer Outdoor Temperature, Average Annual Temperature 20.2℃
Highest Temperature, 38.5℃
Relative Humidity, ≤90%
Ambient temperature cooling in summer. The ambient temperature can be set as the summer standard: it belongs to the south subtropical type (T) 1.5---38.5℃, the cooling parameters are designed according to the subtropical average 32℃ environment, and the summer refrigeration unit can be adopted in winter.
Product Features
Features
(1) Stainless steel conveyor belt;
(2) Sandwich PUF panels 150mm thick, laminated by stainless steel sheet both sides; floor panels are equipped;
(3) Doors are equipped with frame heating device;
(4) Aluminum evaporators, different fin pitches;
(5) Axial fans: stainless steel air box, aluminum blades;
(6) Full welded stainless steel water discharging plate is installed on top of floor panels. It will bring defrosting water out of
cabinet through stainless steel draining pipes;
(7) The inlet device, outlet device and all structure parts are made of stainless steel;
(8) Control panel is made of stainless steel;
(9) Schneider or Siemens electric components;
(10)SEW speed reducer.
(2) Sandwich PUF panels 150mm thick, laminated by stainless steel sheet both sides; floor panels are equipped;
(3) Doors are equipped with frame heating device;
(4) Aluminum evaporators, different fin pitches;
(5) Axial fans: stainless steel air box, aluminum blades;
(6) Full welded stainless steel water discharging plate is installed on top of floor panels. It will bring defrosting water out of
cabinet through stainless steel draining pipes;
(7) The inlet device, outlet device and all structure parts are made of stainless steel;
(8) Control panel is made of stainless steel;
(9) Schneider or Siemens electric components;
(10)SEW speed reducer.
Product Configurations
BASIC PARAMETERS OF SCHEME DESIGN | ||
Frozen product name | Shrimp, Mussel Meat, Scallop Meat, Squid Strips | |
Frozen product size/single weight | none | |
Package style | No device freezing (naked freezing) | |
Placement | directly placed | |
Frozen product feed temperature/℃ | 20℃ | |
Frozen product discharge temperature/℃ | -18℃ | |
Single product freezing time | 10-40min (speed adjustable) | |
Nominal freezing capacity KG/h | 1000KG/H | |
EQUIPMENT DESIGN BASIC PARAMETERS | ||||
1 | device name | Frozen tunnel | ||
2 | structure type | straight line | ||
3 | frozen form | Down blow type | ||
4 | Air supply form | Down and out the back air flow | ||
5 | Dimensions (length*width*height mm) | 15000*2200*2400 | ||
6 | Main cold room length mm | 15000mm | ||
7 | Mesh belt width | 1200mm | ||
8 | Mesh belt form | 316 Stainless Steel | ||
9 | Feed port length | 1000mm | ||
10 | Outlet length | 800mm | ||
11 | Door | 800*1600*150*2 sets | ||
12 | Panel thickness | 15CM | ||
13 | Panel material density | Double-sided stainless steel polyurethane board * 0.5 mm | ||
14 | Energy saving measures | Equipped with air blocking plate and inlet and outlet material wind shield device | ||
15 | Fan frequency modulation | The motor can be adjusted according to the demand of the goods | ||
PARTS CONFIGURATION TABLE | ||||
1 | compressor unit | 90+125 HP Fujihao Screw Evaporative Cooling Unit | ||
2 | air cooler | Customized high-efficiency air cooler, 304 stainless steel air duct, die-cast aluminum impeller, motor protection grade IP55 | ||
3 | condenser | Evaporative condenser | ||
4 | Control System | PLC control electric box + remote monitoring | ||
5 | base frame | Combination of stainless steel sheet metal and stainless steel square tube, fast and corrosion-resistant | ||
6 | Transmission system | Front and rear hubs, brackets, scrapers all 304 stainless | ||
