high quality aluminum 24v dc air sampling pump oil free vacuum pump dc micro vacuum and air diaphragm pump 24 v
- Category: >>>
- Supplier: Tide Smart Technology (shanghai) Co. Ltd.
Share on (1600538444317):
Product Overview
Description
24Vdc brushed motor
Features
Optimized pump body to ensure small volume, provide large
flow and maintain relatively low power consumption.
The gas flow is stable and the motor runs in a wide range.
* High performance shaded pole motor
* lifetime >6000hours
* Imported ball bearing material design
* Professional seal design ensures low leakage rate
* Low leakage rate and pollution-free sample gas
* High quality imported PTFE diaphragm
rubber materials, withstand a variety of gas corrosion
14L/min diaphragm pump
Features
Optimized pump body to ensure small volume, provide large
flow and maintain relatively low power consumption.
The gas flow is stable and the motor runs in a wide range.
* High performance shaded pole motor
* lifetime >6000hours
* Imported ball bearing material design
* Professional seal design ensures low leakage rate
* Low leakage rate and pollution-free sample gas
* High quality imported PTFE diaphragm
rubber materials, withstand a variety of gas corrosion
Model: | AD9KEEDC24 | AD9KTVDC24 |
Voltage range: | 24Vac | 24Vac |
Maximum flow: | 14L/min | 14L/min |
Max. negative pressure: | -80Kpa | -80Kpa |
Max. positive pressure: | 1.5~2Bar | 1.5~2Bar |
Motor type: | 24v brush motor | 24v brush motor |
Max. power: | 30w | 30w |
Waterproof grade: | IP00 | IP00 |
Storage environment temp.: | -40℃~60℃ | 40℃~60℃ |
Working environment temp.: | -20℃~50℃ | -20℃~50℃ |
Pump head material: | PPS | PPS |
Pump diaphragm/valve material: | EPDM/EPDM | PTFE/FKM (anti-corrosion) |
Pump Body material: | Anodic oxidation of aluminum | Anodic oxidation of aluminum |
Red wire connection: | positive pole | positive pole |
Black wire connection: | negative pole | negative pole |
Dimensions(mm): | 122*49*108mm | 122*49*108mm |
