Chc rtk 2022 новейшее RTK GNSS Base и Rover CHC x7/ibase GPS оборудование цена смарт навигация i83 rtk gps
- Category: Other Measuring & Analysing Instruments >>>
- Supplier: Tianjin New Starr Technology Trade Co. Ltd.
Share on (1600560587534):
Product Overview
Description
Product Description
Dimensions:152 mm*78 mm
Weight:1.15Kg
material:magnesium alloy
Working temperature:-45℃+75℃
Storage temperature:-55℃+85℃
Control Handbook
CPU:Octa-core 2.0Ghz processor
Battery:14 hours of battery life
OS:Android 10
Waterproof and dustproof:IP68
Recommend Products
Details Images
Specification
Satellites and Accuracy | Satellite system | GPS+BDS+Glonass+Galileo+QZSS， |
Support Beidou three generations, support five-star twenty-one frequency | ||
number of channels | 1408 | |
Initialization reliability | 99.90% | |
RTK accuracy | Plane accuracy：±( 8 + 1.0×10-6×D) mm | |
Elevation accuracy：±(15 + 1.0×10-6×D) mm | ||
static precision | Horizontal accuracy：±(2.5+ 0.5×10-6×D) mm | |
Elevation accuracy：±( 5 + 0.5×10-6×D) mm | ||
GNSS+Inertial Navigation | IMU update rate | 200Hz |
slope | 0-60 degrees | |
Tilt compensation accuracy | 10 mm + 0.7 mm/° tilt(30°accuracy within<2.5cm) | |
User interaction | LCD screen | Quasi-retina screen, clear and transparent even in direct sunlight |
indicator light | 1 satellite light + 1 differential data light | |
button | Fn function key + power/confirm key | |
web page | Support PC/mobile web pages | |
physical properties | Dimensions | Φ152 mm*78 mm |
Weight | 1.15Kg | |
material | magnesium alloy | |
Working temperature | -45℃+75℃ | |
Storage temperature | -55℃+85℃ | |
waterproof breathable membrane | Prevent water vapor from entering the equipment in harsh environments such as sun exposure and sudden heavy rain | |
Waterproof and dustproof | IP68 (Protection against 1 meter immersion in water for 30 minutes) | |
anti-collision | IK08 (with the same mechanical impact force as a 2.5kg steel ram without damage, 3 meters drop resistance) | |
Electrification parameters | Battery | Mobile station typical 18 hours battery life |
fast charge | Support fast charge, up to 15w fast charge | |
External power supply | ( 9-28）V DC | |
Storage | 8GB | |
electronic bubble | support | |
Wireless communication | Wireless connections | Support Wi-Fi data link |
radio | Built-in transceiver station, support up to 2w transmit power, | |
Support CTI/TT450/Transparent Transmission Protocol | ||
control handbook | model | HCE600 Android Measurement Handbook |
operating system | Android 10 | |
CPU | Octa-core 2.0Ghz processor | |
The internet | 4G full Netcom, built-in eSIM for three years of surveying and mapping traffic | |
LCD screen | 5.5'' HD display | |
Battery | 14 hours of battery life | |
Waterproof and dustproof | IP68 | |
Advanced Features | Smart function | Support super double transmission, super double reception, one key fixed |
Smart service | Support CTI cloud services, provide cloud storage, function code sharing, and provide intelligent road data editing functions |
Company Profile
Our Advantages
FAQ
1. who are we?
We are based in Tianjin, China, start from 2019,sell to Africa(20.00%),Central America(16.00%),Southern Europe(15.00%),Eastern Europe(8.00%),Southeast Asia(7.00%),Mid East(6.00%),Northern Europe(5.00%),North America(5.00%),Western Europe(5.00%),South America(5.00%),Oceania(5.00%),South Asia(2.00%),Eastern Asia(1.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
GPS,RTK,UAV,TOTALSTATION,GNSS RECEIVERS
4. why should you buy from us not from other suppliers?
Tianjin New Starr Technology Trade Co., Ltd. is an electronic product R&D and production-oriented trading company, specializing in the research and manufacture of high-precision GNSS motherboards and industrial
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T；
Language Spoken:English,Chinese,Spanish
We are based in Tianjin, China, start from 2019,sell to Africa(20.00%),Central America(16.00%),Southern Europe(15.00%),Eastern Europe(8.00%),Southeast Asia(7.00%),Mid East(6.00%),Northern Europe(5.00%),North America(5.00%),Western Europe(5.00%),South America(5.00%),Oceania(5.00%),South Asia(2.00%),Eastern Asia(1.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
GPS,RTK,UAV,TOTALSTATION,GNSS RECEIVERS
4. why should you buy from us not from other suppliers?
Tianjin New Starr Technology Trade Co., Ltd. is an electronic product R&D and production-oriented trading company, specializing in the research and manufacture of high-precision GNSS motherboards and industrial
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T；
Language Spoken:English,Chinese,Spanish
