item | value |
Warranty | 1 years |
Customized support | OEM, ODM |
Place of Origin | China |
Brand Name | GNSS NEW STAR |
Model Number | NST-CGX601A |
Specifications NST-CGX601A | ||
Antenna characteristics | ||
Frequency Range | GPS L1/L2/L5 | |
BDS B1I/B2I/B3I/B1C/B2a/B2b | ||
GLONASS L1/L2/L3 | ||
GALILEO E1/E5a/E5b/E6 | ||
QZSS L1/L2/L5/L6 | ||
IRNSS L1/L5 | ||
L-Band | ||
impedance | 50 ohms | |
Polarization mode | right-handed circular polarization | |
Horizontal plane coverage angle | 360° | |
output standing wave | ≤2.0 | |
highest gain | 7dBi | |
Phase center error | ±1mm | |
Low Noise Amplifier Specifications | ||
gain | 50±2dB | |
Noise Figure | ≤2dB | |
output standing wave | ≤2.0 | |
In-band flatness | ±2dB | |
Operating Voltage | +3.3~+12VDC | |
Working current | ≤60mA | |
differential propagation delay | ≤5ns | |
Structural properties | ||
Antenna size | φ379*312mm | |
weight | Bare metal 9.3kg | |
10.5kg with packaging | ||
Connector form | TNC Pussy | |
Installation method | 5/8 ''*11 teeth (with north direction on the base) | |
working environment | ||
Operating temperature | -40℃~+85℃ | |
storage temperature | -55℃~+85℃ | |
humidity | 95% non-condensing | |
