Full hd 5MP human recognition long night vision distance outdoor surveillance kit POE NVR cctv system
- Category: Surveillance Systems >>>
- Supplier: Shenzhen Zhaoyang Shidai Technology Co. Ltd.
Share on (1600599690766):
Product Overview
Description
Full hd 5MP human recognition long night vision distance outdoor surveillance kit POE NVR cctv system
Product Description
(Below is the specification of 1080P, for 5MP, please contact sales for more information)
WHY CHOOSE H.265?
1. Reduces file size up to 50% with the same quality;
2. Save 50% bandwidth;
3. Low bit rate: H.265 has a low bit rate similar to H.264;
4. Extend far greater video quality experience compared to H.264
CAMERA CHARACTERS:
1) . Dual stream encoding(H.265)
2) . Cmos Sensor
3) . With IR-CUT, support day/night switch
4) . 1080P, 1-25fps adjustable
5) . 3.6mm 1080P fixed lens
6) . 6pcs led, 10-20m ir distance for night vision
7) . Multi-screen software and CMS, free app
8) . Support motion detection, P2P, supportONVIF
9) . Support remote control by smart phone,iphone/android.
NVR Features:
1. 16ch 1080P realtime viewing, recording & playback;
2. 1CH VGA/HD video output;
3. Support mobile phone monitoring;
4. Support 1 SATA HDD, max capacity 8TB (HDD Not Included);
5. POE fuction; with 8 ports Rj45, direct connect with camera and offer power;
6. APP: MEEYE / Seetong
Specification
| Operating System | Embedded LINUX operating system | |
| Video Standard | H.265+/ H.265/H.264 | |
| Smart Analysis | With Smart IPC,suppoat | Target Count, Object Left /Lost, Area Detection, Line Crossing |
| Video & Audio Input | Video Input | 9CH 1080P IP Network Cameras |
| Audio Input | IPC composite stream network audio input | |
| Video & Audio Output | HDMI Output | 1CH, HDMI can output audio at the same time |
| VGA Output | 1CH | |
| Preview Split | 1/8/16 screen | |
| Video & Audio Codec | Video Resolution | 1080P and below resolution |
| Synchronized Playback | Support adaptive stream preview and playback:9 screens D1, 4 screens 1280*720, single screen 1920*1080 | |
| External Ports | Internet | 1 x RJ45 10M/100M/1000M adaptive Ethernet port |
| USB | 2 x USB2.0 rear | |
| HDD | HDD Port | 1 x SATA HDD Port |
| MAX Capacity | up to 8TB | |
| POE | interface | 8xRJ45 10M/100M adaptive Ethernet port |
| Support Standard | IEEE802.3af | |
| Network Management | Network Protocol | UPnP (Plug & Play), SNMP (Simple Network Management), NTP (Network Timekeeping), SADP (Device Network Search), SMTP (Mail Service), NFS (Access NAS), iSCSI (IP SAN Application), PPPoE (Dial-up Internet access), DHCP (automatically obtain IP address) |
| P2P Remote Monitoring | AEeye | Supports iPhone, iPad, Android Smart phone |
| Supports Windows 7 and above computer client, supports Apple MAC computer client | ||
| Power Supply | 52V 1.5A | |
| Working Temperature | -10℃--+55℃ | |
| Working Humidity | 10%-90% | |
| Power Consumption | POE power consumption≤40W;NVR motherboard function≤8W(Without HDD) | |
Packaging
Package Included :
*8pcs POE IP Cameras;
*1pc H.265 8 ports POE NVR;
*1pc USB Mouse;
*1pc 52V/1.3A Power Supply (For NVR);
*8pcs 18m Network Cables (For Camera);
*1pc QR code User Manual.
Company Information
Related Products
Certifications
CE, Rohs, FCC, IC-ISED, PSE.
FAQ
Q: Are you a manufacturing company?
A: Yes, SV3C is a middle size manufacturing company which has factory located in Shenzhen, China.
Q: Do you support OEM?
A: Of course, OEM is also our main business range.
Q: What certificates are approved for your products?
A: CE, Rohs, FCC, IC-ISED, PSE,Telec certificated.
Q: How is the delivery time?
A: According to the quantity, normally less than 1000pcs will send out by 5 -10 days.
Q: How can we be your distributor?
A: According to different area, product items and quantity to evaluate. Kindly contact us for detail negotiation.
Q: What about your technical Support?
A: Firstly, we have perfect and detail instruction manual in various languages. Secondly, we have a technician team to provide technical support.
Q: Do you provide free samples?
A: Dear, our sample fee will return if you order bulk sell quantity.
