High accuracy Tablet Hardness Tester FM 204T

Product Overview

Description

Tablet Hardness Tester FM-204T

Spec:0-20Kgf,0-196N,0-4426F

Model:FM-204T

Features

* High precision and high resolution.

* Digital display, ignore the difference.

* N(Newton), kg(kg), 1B (pounds),

 *g(grams) four measuring units for choice, mutual conversion.

* Peak hold function. Maintain peak display until manually reset.

* Can be powered by alkaline batteries; Can also be connected to 5V DC power supply.



Principle

Fm-204t series tablet hardness tester is a digital display tablet hardness tester designed and developed by our company. It has the advantages of high precision, easy operation and convenient carrying. The scientific use test range is 10%-100% of the full scale. The metrology department recommends not to use less than 1% of the full scale. At the same time, after the instrument and the object to be tested are in place before the test,press the ZERO(ZERO) key to clear the ZERO to eliminate the weight of the fixture.



Specifications



Test scope	0Kgf-20Kgf,0N-196N,0F-4426F
The resolution	0.01Kgf,0.1N,0.0126F
Diameter of the test range	15mm
Precision	±0.5%FS (range) + 1 digital peak
Unit	kgf, gf, N, Lbf
Can be measured value	Peak, instantaneous value.
According to	Four big liquid crystal, the direction, double screen
Backlight	Backlight
Allow the load	150%F.s (super 110% E.s, beeping alarm)
The power supply	Section 2 battery 5 or 5 v dc power supply
Working temperature	0°C~50°C
Working humidity	<80%
The work environment	Around the source and the corrosive medium
Turnning	390g
Size	211mmx80mmx36mm
