Алюминиевые Декоративные жалюзи для вентиляционного кондиционера
- Category: HVAC Systems & Parts >>>
- Supplier: Henan,Retop,Industry,Co.,Ltd.
Share on:
Product Overview
Description
Name | Single deflection Aluminum air grille |
Material | Aluminium alloy |
Function | Ventilation opening |
Size | Customized Size |
Color | Customized Color |
Warranty | 5 Year |
After-sale Service | Online technical support |
Project Solution Capability | graphic design |
Application | Office Building |
Design Style | Modern |
Place of Origin | Henan，China |
Construction:
* Ø Frame: High quality extruded aluminum alloy(A6063) profile with 30mm flange as standard.
* Ø Blades: Aerofoil blades in 45° from aluminum profile
* Ø Blades spacing: 35mm as standard
* Ø Support pipe: 8mm diameter aluminum pipe
* Ø Frame: High quality extruded aluminum alloy(A6063) profile with 30mm flange as standard.
* Ø Blades: Aerofoil blades in 45° from aluminum profile
* Ø Blades spacing: 35mm as standard
* Ø Support pipe: 8mm diameter aluminum pipe
Description:
* Ø Fresh air louver is composed of frame and horizontal blades assembly, manufactured from high quality extruded aluminum profile construction with advantages of corrosion resistance and rigidity.
* Ø Blades are set at angle of 45° with 30mm spacing, and fixed to the inner frame by rivets and support pipe.
* Ø Total structure is weather proofed and blades are inclined down wards to protect against rain water.
* Ø Structure provides around 45% effective pressure area .
* Ø Fresh air louver is composed of frame and horizontal blades assembly, manufactured from high quality extruded aluminum profile construction with advantages of corrosion resistance and rigidity.
* Ø Blades are set at angle of 45° with 30mm spacing, and fixed to the inner frame by rivets and support pipe.
* Ø Total structure is weather proofed and blades are inclined down wards to protect against rain water.
* Ø Structure provides around 45% effective pressure area .
Item code | Neck size(mm) | Face size(mm) |
RT-A | 200x200 | 255x255 |
RT-A | 300x200 | 355x255 |
RT-A | 400x200 | 455x255 |
RT-A | 500x300 | 555x355 |
RT-A | 600x300 | 655x355 |
Henan Retop Industry Co., Ltd. is the leading manufacturer of aluminum profiles in China for the construction, decoration and industries fields. Since 2003 of our establishment in Zheng-zhou City, We have passed the SGS ISO 9001:2008/9001:2015/140001:2004 certification,we have supplied domestic and abroad market with high-quality products and best service for over 18 years.
Q1：
Are you a factory or trading company? A: we're a self -own factory, with export license.
Are you a factory or trading company? A: we're a self -own factory, with export license.
Q2：
Location? How can I visit there?
A: Our factory locates in Zhengzhou, Henan, China. The nearest airport is Xinzheng airport.
Q3：
Lead time for new molds &mass production?
A: 7-10 days to build the new moulds. Mass production takes 20-25days for a 20gp,25-30days for a 40hq.
Q4：
What certification do you have?
A: we are certificated by ISO 9001:2008, factory is reliable and quality is guaranteed.
Q5：
Payment terms?
A: Telegraphic Transfer (T/T) and Letter of Credit (L/C).
Q6：
Can you send me samples?
A: Yes, Free samples, with freight is on your side.
Location? How can I visit there?
A: Our factory locates in Zhengzhou, Henan, China. The nearest airport is Xinzheng airport.
Q3：
Lead time for new molds &mass production?
A: 7-10 days to build the new moulds. Mass production takes 20-25days for a 20gp,25-30days for a 40hq.
Q4：
What certification do you have?
A: we are certificated by ISO 9001:2008, factory is reliable and quality is guaranteed.
Q5：
Payment terms?
A: Telegraphic Transfer (T/T) and Letter of Credit (L/C).
Q6：
Can you send me samples?
A: Yes, Free samples, with freight is on your side.
