HG8546M EG8141A5 XPON Best price Original Huawei 5DB wifi GEPON ONU 4LAN 1voice WIFI USB Antenna ONU ONT English Version 8546m

Product Overview

Description

                     Huawei GPON ONT EG8141A5 HG8546M



Brand New Indoor Huawei GPON ONT,Gateway Terminal FTTH HG8546M 4FE+1POTS+1USB+WIFI,Fiber Optic Equipment GPON ONU

1.Product description of HG8546M

The EchoLife HG8546M, an optical network terminal (ONT), is a high-end home gateway in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The H8546M provides 1* POTS ports, 1*GE+3* FE auto-adapting Ethernet ports, and 2* Wi-Fi port. The H8546M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the H8546M provides a perfect terminal solution and future oriented service supporting capabilities for FTTH deployment.





2.Product parameter of HG8546M

Model	Internet Ports	Voice(tel)	Router (PPPOE)	Wifi	Firmware language
HG8546M	4FE	1	support	support	English
	Power plug:EU,AU,AM,UK etc			Noted: with Chinese manual

3.Products feature and application of HG8546M

Maintenance features
 *Local management using Web and remote management using TR069 and OMCI
 *Optical power monitoring
 *802.1ag Ethernet OAM
 *Loop-line test of POTS ports,call emulation and PPPoE dialup emulation

GPON features
 *Class B+ optical module
 *Security authentication mode: SN,
 password or SN+password
 *Upstream/downstream FEC

Routing features
 *NAT function
 *Internet, IPTV and VoIP services are automatically bound to ONT ports
 *Virtual server, port trigger, DMZ,and DDNS

Reliability features
 *Dual systems for software protection
 *Type B protection and rogue ONT detection
 *Lithium battery backup and backup battery monitoring

Voice features
 *SIP and H.248 protocols
 *Media stream and signaling stream separation

Multicast features
 *IGMP V2&V3 snooping/IGMP proxy

Wi-Fi features
 *802.11b/g/n, certified by the Wi-Fi Alliance

4.Product details of the HG8546M

 *Dimensions(W x D x H):250 mm x 185 mm x 35 mm
 *Port:1POTS+1GE+3FE+1USB+1Wi-Fi
 *Average power consumption:8 W
 *Operating environment:Temperature: 0℃~+40℃;
 *Humidity: 5%–95%, non-condensing
 *Power supply:Adapter input: 100–240 V AC, 50–60Hz;
 *Adapter output: 11–14 V DC, 1 A
 *Weight:About 500g (including the power adapter)

5.Delivery time, package and service of HG8546M

Delivery Time:	5-10working days after we receive the payment
Shipping:	By DHL; By Air; By Sea
Package:	Original Huawei Pakcage
Service:	Technical support; 1 year warranty

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?
A: Generally, it will take 5-7 working days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
