perforated plastic cable management channel making roll forming machine cable tray
- Category: Machine Tools Accessories >>>
- Supplier: Jiangsu Krius Machine Parts And Accessories Co. Ltd.
Share on (1600638480313):
Product Overview
Description
Product Information
| Item NO. | Bending raduis | Crossbar width | Inner height*Inner width | Outer height*Outer width | pitch | Weight per meter |
FN15 semi-closed type with tie wrap clamp plate cable chain | 25/28/38/48 | 15 | 15*15.2 | 19.5*24.8 | 25 | 0.3kg/m |
| 20 | 15*20.2 | 19.5*29.8 | 0.3kg/m | |||
| 30 | 15*30.2 | 19.5*39.8 | 0.3kg/m | |||
| 40 | 15*40.2 | 19.5*49.8 | 0.38kg/m | |||
| 50 | 15*50.2 | 19.5*59.8 | 0.4kg/m | |||
FN18 semi-closed type with tie wrap clamp plate cable chain | 28/38/48/75/100/ 110/125/145/180 | 18 | 18*18.2 | 23*30.2 | 30 | 0.37kg/m |
| 25 | 18*25.2 | 23*37.2 | 0.41kg/m | |||
| 35 | 18*35.2 | 23*47.2 | 0.45kg/m | |||
| 40 | 18*40.2 | 23*52.2 | 0.47kg/m | |||
| 50 | 18*50.2 | 23*62.2 | 0.55kg/m | |||
| EN15 series bridge type cable chain | 23/28/38/48 | 15 | 15*15.2 | 19.5*24.8 | 25 | 0.3kg/m |
| 20 | 15*20.2 | 19.5*29.8 | 0.28kg/m | |||
| 30 | 15*30.2 | 19.5*39.8 | 0.33kg/m | |||
| 40 | 15*40.2 | 19.5*49.8 | 0.34kg/m | |||
| 50 | 15*50.2 | 19.5*59.8 | 0.37kg/m | |||
| EN18 series bridge type cbale chain | 28/38/48 | 18 | 18.1*18.2 | 23*29.2 | 30 | 0.4kg/m |
| 25 | 18.1*25.2 | 23*36.2 | 0.4kg/m | |||
| 35 | 18.1*35.2 | 23*46.2 | 0.4kg/m | |||
| 40 | 18.1*40.2 | 23*51.2 | 0.5kg/m | |||
| 50 | 18.1*50.2 | 23*61.2 | 0.52kg/m |
Product Application
Product Process
About us
Certification
FAQ
Q: Are you trading company or maunfacture ?
A: We are maunfacture . our company integrated the research $ design production and sales into a whole.
Q:How long is your delivery time.
A: Generally it is 5~7 days if goods are in stock. or it is 7~15 days if the goods are not in stock . it is according to quantity
Q: Do you provide sample ? is it free or extra?
A:Yes . we provide samples for free but but we do not pay the delivery cost
Q: What is your terms of payment?
A: payment ≤1000 USD 1000% in advance payment ≥ 1000USD 50%T/T in advance , balance before shipment.
