Motorized bicycle engine kit

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description









Brand Name
ZTMOTO
Model Number
85 V3
Bore
52mm
Ignition Mode
Upgraded CDI
Feature
Speed carb, reed valve, double window piston
Suitable for
Mountain bikes/beach bikes/etc.
Engine type
Single Cylinder
Starting
Kick starting
Package
Custom Packaging
Muffler
Pure stainless steel
Fuel/Oil Ratio
New engine (<310 miles): 20:1, after break In: 25:1
Power
Over 3HP








ZTMOTO 85 Features Include
* 52mm Bore, 40mm Stroke - Actual U.S. engine displacement: 85cc
* Single piece cylinder and head (Lower operating temps, increased rider weight capacity, improved power output across varied rpm
range)
* High performance Speed carb
* Reed Valve (Controls air-fuel mixture flow to increase performance)
* Ceramic lined cylinder (Significantly improves cylinder durability, reduces friction, lowers operating temps, increases
performance)
* All new ultra-quiet exhaust pipe
* Oversized exhaust port
* High performance CDI with Yamaha components
* Performance magneto
* High end allen bolts
* Improved gas cap
ZTMOTO 85 Engine Kit Includes
* 85cc 2 stroke engine with one piece cylinder and head
* Reed valve air intake
* Needle bearing for piston wrist pin
* High performance Speed carb
* Angled LD Z8C spark plug
* Performance magneto
* Stainless steel allen bolts
* Better balanced crank
* Upgraded bearings / 60% thicker crank case around bearings
* Stuffed crank case
* Large intake port (40mm bolt hole width)
* Oversized round exhaust port - 28mm diameter, 60mm stud spacing
* 40mm crank stroke (more powerful, efficient, and reliable)
* Double window piston
* Long rod (89mm)
* Larger 8mm x 1.25 engine mount studs
* Approximate engine dimensions:
9" x 9" x 5"
Mounting Kit & Accessories Included
* High performance CDI with Yamaha components
* Black tear drop gas tank (2L) w/ new fuel cap, fuel valve, fuel filter, and fuel line
* 415 Heavy duty chain with chain guard
* Ball bearing chain tensioner
* Ultra quiet muffler (Stainless steel with sound insulation cotton inside)
* Throttle assembly w/gooseneck style throttle cable
* Twist throttle and cable with matching grip and kill switch
* New quick release clutch handle
* Large front mount for bicycles that have large down tubes
* Available with 36, 44, or 48 tooth rear sprocket
* Spark plug socket tool and gear removal tool
Improved Intake Port and Transfer Port, more horsepower
