BFS-S Fire Fighter Satety Switch for Solar Building

● As the firefighter cut off the AC power in the house, the safety switch will disconnect the DC power at the sametime.

● Over temperature protection

● IP66 aluminum durable enclosure

● Plug and Play easy installation

● Emergency button for 100% disconnect

● 5 years warranty

Application
The BFS-S Series FireFighter Safety Switch is a DC disconnect solution for solar rooftop fire protection.
Provide DC power mechanical and complete isolation in the event of a fault. Make a safe area and operating space to protect the firefighter from DC electric shock.


Product Paramenters


Model
BFS-S
Max DC voltage IEC/EN 60947-3
1500V/1350V/1000V/800V
Max DC current IEC/EN 60947-3
50A
Model No.
BFS-S4
Number of Strings
4 string
Operating Voltage
90Vac-260Vac
Nominal Voltage
230Vac
Nominal Current
30mA
Start up Current
average 100mA
Switch on Action Current
Max 300mA
Standard Compliance
IEC / EN 60947-3
Protection Degree
IP66
Storage Temperature Allowed Between
-40℃ to +85℃
Operating Temperature Range
-20℃ to +50℃
Maximum Operating Temperature Before
Automatic Switch OFF
+85℃
Protection Level
Class ll


Mechanical Endurance

9700
Electrical Endurance
300
Warranty
5 Years
