Product Overview

Description






Product Description




BNC connector Coaxial cable surge protector OBVW is the series of devices for discharging transient overvoltages induced in coaxial lines. In accordance with IEC 61643-21. Coaxial format.





Suitable for the protection of radiofrequency transmission and reception equipment. By their nature, they are highly exposed to induced transient overvoltages (surges) associated with meteorological activity.


For BNC, F, N, TNC connectors.


Ideal for the protection of transmission and reception systems such as TV and radio antennas, closed circuit TV (CCTV), alarms, etc.











































































OBVW-


BNC/75C



OBVW-


BNC/50C



OBVW-


N/75C



OBVW-


N/50C



OBVW-


F/75C



OBVW-


F/50C



Maximum Continuous Operating Voltage Uc (~)



DC68V / AC130V / AC280V



Nominal Discharge Current In (8/20µs)kA



10kA



Maximum discharge current Imax (8/20µs)kA



20kA



Maximum peak power (W)



<300



Interface



BNC



N



F



Voltage protection level (Up)



<600V



Bandwidth (MHz)



0-3000



Standing wave ratio, VSWR



≤1.2



Insertion Loss



≤0.1db



Impedance(Ω)



75Ω



50Ω



75Ω



50Ω



75Ω



50Ω







Dimension



















application


2.Application (1).jpg2.Application (2).jpg





Certifications







Company Information


5.About US (1).jpg





contact information


6.Contact US.jpg





FAQ


Q: Can I get some samples?


A: Yes, Sample orders welcomed.





Q: Can I use my own Logo or design on goods?


A: Yes, Customized logo and design on mass production are available.





Q:What is the delivery time?


A: 3 days for samples, 7-15 days for mass production.





Q: What is the payment term?


A: T/T, L/C at sight, West union , Paypal, etc





Q: Can I trust you?


A: Absolutely YES, We are “Alibaba” verified supplier for many years.





Q: May I visit your factory?


A:Sure, welcome any time. We can also pick you up at airport or station.
