Good Service Asphalt Paver Finisher Asphalt Spreader 4.5M RP453L Asphalt Concrete Paver in Philippines
- Category: >>>
- Supplier: Maxizm Construction Machinery (Qingdao) Co. Ltd.
Share on (1600744464375):
Product Overview
Description
Contact Us
Product Overview
RP453L Automatic Mini Asphalt Paving Machine Asphalt Concrete Paver 4.5M paver asphalt pavers
RP453L paver is a hydraulic-driven small wheeled paver with <5m paving width. It’s especially suitable for the constructions with specific construction quality requirements, including small roads, urban road construction, and classified highway maintenance, and can meet the constructions under narrow working conditions, including sidewalks, auxiliary lanes, non-motorized vehicle lanes, and ditches.
PRODUCT SPECIFICATIONS
Items | Unit | Parameters |
Basic paving width | m | 2 |
Max. paving width | m | 4.5 |
Max. paving thickness | mm | 150 |
Paving speed | m/min | 0~13 |
Travel speed | km/h | 0~13 |
Theoretical Productivity | t/h | 240 |
Hopper Capacity | t | 12 |
Gradeability | % | 20 |
Pavement evenness | mm/3m | 3 |
Transverse levelling accuracy | % | ±0.03 |
Centre crown ratio | % | 0~+3 |
Engine model | 4JR3G1 | |
Engine power | kw | 55 |
Engine speed | r/min | 2200 |
Fuel tank capacity | L | 130 |
Machine weight | t | 10.5 |
Dimension | mm | 5690X2070X3590 |
Auger speed | r/min | 0~73 |
Conveyor speed | m/min | 0~30 |
Vibration frequency | Hz | 3~42 |
Screed heating | Gas heating | |
Auger and conveyor control | Automatic Control by Ultrasonic Sensors | |
Automatic levelling control | Simulation Control Simulation control |
