Product Overview
Description
Product Description
The Blister packing machine is of flat-plate structure, with pressing, molding, meshes heat-sealing, adjustable travel range, for small size of body and ease of operation. It is applied to Al-Al, Al-PVC, Al-plastic packaging for capsule, table, candy, healthcare, small hardware etc. It is widely used in small pharmacy factory, preparation-room of hospital institute laboratory, mini-motor test workshop. The machine reaches advanced level in China.
Feature
◆ Faster Speed-Double heater plate and roller type sealing, .
◆ Easier Operation-Adopts top brand PLC controller displayed in Chinese and English, speed control, the length of blister traction adjustable
◆ Thermal temperature control and test, over loading protect, PVC and PTP packing material position test, feeder, material position test, failure automatic debug and alarm, automatic protection and stop running.
◆ Ensuring accurate registration -Adopts auto photoelectric register device for patterns and words of Al foil driven by step motor, perfect performance.
◆ Discharging finished product in right order -automatic collection of bad products, auto rewinding of strap material to ensure easy collection.
◆ Auto close and opening of forming plate helps delay the running time after dropping down the heat plate and also makes packing material efficiently used.
◆ High Feeding efficiency, reliable and suitable for many kinds type arrange and irregular feeding,(according to actual product design fit feeder)
◆ Auto alarm and stop of machine when PVC finds in lack or ruptured, provides much convenience to operator for timely PVC replacement or joint PVC.
◆ "GMP" requirements -All parts contact with material including hopper adopt high level stainless steel.
◆ Easier Operation-Adopts top brand PLC controller displayed in Chinese and English, speed control, the length of blister traction adjustable
◆ Thermal temperature control and test, over loading protect, PVC and PTP packing material position test, feeder, material position test, failure automatic debug and alarm, automatic protection and stop running.
◆ Ensuring accurate registration -Adopts auto photoelectric register device for patterns and words of Al foil driven by step motor, perfect performance.
◆ Discharging finished product in right order -automatic collection of bad products, auto rewinding of strap material to ensure easy collection.
◆ Auto close and opening of forming plate helps delay the running time after dropping down the heat plate and also makes packing material efficiently used.
◆ High Feeding efficiency, reliable and suitable for many kinds type arrange and irregular feeding,(according to actual product design fit feeder)
◆ Auto alarm and stop of machine when PVC finds in lack or ruptured, provides much convenience to operator for timely PVC replacement or joint PVC.
◆ "GMP" requirements -All parts contact with material including hopper adopt high level stainless steel.
Specification
Model | DPP-140 | DPP-250 |
Punching Frequency | 15-45 cutting/min | 15-45 cutting/min |
Max Forming Area and Depth | 140x110x15mm (Max 20mm） | 250 x 120 x 15mm (Max 30mm) |
Adjustable Pulling Length | 30-120mm | 30-130mm |
PVC | (0.15-0.6)x160xΦ350mm | (0.15-0.4) x 260 x Φ400mm |
PTP(Alu Film) | (0.02-0.15)x160xΦ350mm | (0.02-0.15) x 260 x Φ400mm |
Paper | (50-100)g/㎡x160xΦ350mm | (50-100)g/㎡ x 260 x Φ400mm |
Power(Three Phase) | 380V 50HZ 5.5KW | 380V 50Hz 8KW |
Air Supply | 0.6-0.8Mpa ≥0.4m³/min | 0.6-0.8Mpa ≥0.45m³/min |
Water Colling Consumption | 40-80L/h | 40-80L/h |
Dimension | 2400x650x1450mm | 900 x750 x1600mm |
Net Weight | 800kg | 1200kg |
