UV 8000TS variable bandwidth dual beam uv visible Spectrophotometer double beam spectrophotometer

Share on (1600796484792):


Price:$3,500.00

Quantity:


Product Overview

Description



Products Description




Product Paramenters


[Features]
1. Adopt dual beam optical system with precision vertical-type dual optical path and dual detector.
2. Imported grating of high performance greatly reduced the stray light and improved the stability and reliability of device.
3. 10 inches large touch screen, built-in 32G memory, support Bluetooth connection network.
4. Three operation modes are available: Host, Computer and Mobile phone (App).
5. Powerful data analysis system with internal computer host could realize multi functions independently. Like establishing calibration curve, photometric measurement, quantitative measurement, spectral scanning, dynamics, DNA/Protein test,
multi-wavelength analysis and data printing.
6. Optical system adopts suspension design. All optical parts are independently fixed on the 8mm thick aluminum
deformation-free base to avoid the impact of bottom plate deformation and outside vibration on optical system.
This premium design greatly improved the stability and reliability of the instrument.
7. Convenient data storage and printing function. UV-8000T can be directly connected to the printer for A4 format data and graph printing.
8. Automatic power on self test and system positioning function could inspect and calibrate the deviation before every use.
9. All test data and analysis report can be exported to USB disk directly.
10. PC software is in compliance with 21CFR PART 11 requirements.
11. Graphs support 3D display.


Model
UV-8000T
UV-8000TS
Wavelength Range
190-1100nm
The spectral bandwidth
1.8 nm
0.5, 1.0 2.0, 4.0nm
Wavelength Accuracy
±0.1nm(D2 656.1nm),±0.3 nm full range
Stray light
0.03%T @ 220 nm, 360 nm
Wavelength Repeatability
≤0.1nm
Photometric Accuracy
±0.2T(0-100%T)
±0.002Abs(0-0.5Abs)
±0.004Abs(0.5-1.0Abs)
Photometric Repeatability
≤0.05%6T(0-100%6T)
0.001Abs(0-0.5Abs)
0.002Abs(0.5-1.0Abs)
Stability
≤0.0005A/h@250nm, 500nm
Photometric Range
0-200%T, -0.3-3.0A, 0-9999C
Baseline flatness
±0.0008A
Display
800*480 touch screen
Output
USB port & Parallel Port
Light source
Tungsten Lamp & Deuterium Lamp
Power Requirements
AC 220V/50Hz or AC 110v/60Hz
Detector
Silicon Photodiode
Dimension
630*430*210nm
Weight
28kg


Recommend Products




Our Advantages




Company Profile








Certifications




Product packaging




FAQ



Who are we?
Shanghai Metash Instruments is a professional manufacturer of science laboratory instruments, with over 12 years manufacturing and exporting experience.

What product do we have?
We manufacture full range of Spectrophotometers, TOC analyzer and Microwave digestion system and related accessories.

What certificate do we have?
All our products are CE, ISO, RoHS certified and have been exported to over 90 countries, over 80,000 Metash devices are serving for environmental, food, cosmetics, pharmaceutical, life science and chemical fields, etc.

What is the MOQ?
The MOQ is 1unit.

Do we accept OEM order?
Yes. We welcome OEM cooperation and will try our best to meet your special OEM requests.
