Price:$0.03

Quantity:


Product Overview

Description









Products Description




Applications


1, Amusement
2, Indoor lighting
3, Architecture lighting
4, Decorative lighting


Maximum Rating (Ta=25℃)


Parameter
Symbol
Value
Unit
DC forward current
IF
30
mA
Pulse forward current
IPF*3
70
mA
Reverse voltage
VR
5
V
Junction temperature
TJ
110
℃
Operating temperature range
TOP
-40~85
℃
Storage temperature range
TSTG
-40~100
℃
Soldering temperature
TSD*2
260
℃
Notes:
1, There is no maximun or typical voltage parameter.
2, For other ambient, limited setting of current will be depended on de-rating curves.
3, Duty 1/10, pulse width 0.1ms.
4, The maximum of soldering time is 5 seconds in TSD


Typical Product Characteristics (Ta=25℃)


Parameter
Symbol

Min.
Typ.
Max.
Unit
Test Condition
                                                                      Forward Voltage
                     VF
Red
1.8
-
2.6
                       V
                                                                IF= 20mA
Green
2.8
-
3.6
Blue
2.8
-
3.6
Whiye
2.8
-
3.6
                                                                                                                Luminous Intensity
                          IV
Red
500
-
1400
                                mcd
                                                                                                  IF= 20mA
Green
1400
-
4000
Blue
290
-
850
White
1400
-
4000
                                                                        Dominant Wavelength
                  λd
Red
618
-
628
                        nm
                                                               IF= 20mA

Green
520
-
530

IF= 60mA
Blue
460
-
475
                                                                                                                    Color Coordinate
        RGB
x
-
0.255
-

                                                                                                    IF= 20mA
y
-
0.236
-

          W
x
-
0.3452
-

y
-
0.3558
-

Reverse Current
IR
-
-
10
uA
VR=5V
View Angle
2θ1/2

-
120
-
Deg
IF= 20mA
Notes:
1, Tolerance: Forward Voltage: ±0.1V, Luminous Intensity: ±10%Iv, Dominant Wavelength: ±1.0nm
2, Electrical-optical characteristics (Ta= 25℃).
3, We will amend the Bin code to maintain Bin Code centralize.
4, And we get the Luminous Intensity is 1.3double per Bins and the Dominant Wavelength is 5/5/5nm of R/G/B per Bins and white balance.


Dimensional Drawing


Notes:
1, All dimensions are in millimeters.
2, Tolerance is ±0.1mm unless otherwise noted.
3, Specifications are subject to change without notice.
