AS5040 SS_EK_AB Programmable Magnetic Rotary Encoder AS5040 sensor module sends magnets
- Category: >>>
- Supplier: Shenzhen Chenyusheng Technology Co. Ltd.
Share on (1600938473073):
Product Overview
Description
Paramenters
AS5040-SS_EK_AB Programmable Magnetic Rotary Encoder AS5040 sensor module sends magnets
AS5040 is a contactless magnetic rotary encoder used to measure angles throughout the entire 360 ° range. This product is an on-chip system that integrates integrated Hall components, analog front-end, and data signal processing functions within a single package.
When measuring angles, simply equip a bipolar magnet that rotates above the center of the chip. The magnet can be installed above or below the IC. This angle measurement method can instantly indicate the angular position of the magnet, with a resolution of 0.35 °, which means 1024 positions per turn. Digital data can be presented in the form of serial bit streams or PWM signals. In addition, it can also provide users with programmable incremental outputs, making this chip very suitable for replacing various optical encoder products. AS5040 has a built-in voltage regulator that allows it to operate at 3.3V or 5V power supply voltage.
1.1 Advantages
-Complete on-chip system
-Flexible system solution, while also providing value strings
Row output, PWM output, and incremental output
-Due to the use of contactless detection methods, the working environment is harsh
The application is very ideal
-Capable of withstanding magnet position deviation and air gap changes
-No need for temperature compensation
-No calibration required
1.2 Main characteristics
-Realize contactless, high-resolution rotation throughout the entire 360 ° range
Position encoding
-Two types of digital, 10 bit value outputs:
-Serial interface output, and
-Pulse width modulation (PWM) output
-Three incremental output modes:
-Orthogonal A/B and Index output signals
-Step/direction and index output signals
-3-phase commutation suitable for brushless DC motors
-Programmable resolution for 10, 9, 8, or 7 users
-User programmable zero/index position
-Implement fault detection mode for magnet position monitoring and power-off monitoring
-The rotation speed can reach up to 10000 rpm
-The button function that can detect the movement of magnets along the Z-axis
-Can use daisy chain connection mode to read multiple interconnected data in series
AS5040 device
-Wide temperature range: -40 ° C to+125 ° C
-Fully compliant with AEC-Q100, Level 1 specifications in the automotive industry
-Small lead-free package: SSOP 16 (5.3mm x 6.2mm)
1.3 Application
-Industrial applications:
-Contactless rotation position detection
-Robotics Technology
-Brushless DC motor commutation
-Electric tools
-Automotive applications:
-Steering wheel position detection
-Throttle position detection
-Transmission gearbox encoder
-Headlight position control
-Electric seat position indicator
-Office equipment: printers, scanners, copiers
-Replace optical encoders
-Front panel rotary switch
-Replace potentiometer
When measuring angles, simply equip a bipolar magnet that rotates above the center of the chip. The magnet can be installed above or below the IC. This angle measurement method can instantly indicate the angular position of the magnet, with a resolution of 0.35 °, which means 1024 positions per turn. Digital data can be presented in the form of serial bit streams or PWM signals. In addition, it can also provide users with programmable incremental outputs, making this chip very suitable for replacing various optical encoder products. AS5040 has a built-in voltage regulator that allows it to operate at 3.3V or 5V power supply voltage.
1.1 Advantages
-Complete on-chip system
-Flexible system solution, while also providing value strings
Row output, PWM output, and incremental output
-Due to the use of contactless detection methods, the working environment is harsh
The application is very ideal
-Capable of withstanding magnet position deviation and air gap changes
-No need for temperature compensation
-No calibration required
1.2 Main characteristics
-Realize contactless, high-resolution rotation throughout the entire 360 ° range
Position encoding
-Two types of digital, 10 bit value outputs:
-Serial interface output, and
-Pulse width modulation (PWM) output
-Three incremental output modes:
-Orthogonal A/B and Index output signals
-Step/direction and index output signals
-3-phase commutation suitable for brushless DC motors
-Programmable resolution for 10, 9, 8, or 7 users
-User programmable zero/index position
-Implement fault detection mode for magnet position monitoring and power-off monitoring
-The rotation speed can reach up to 10000 rpm
-The button function that can detect the movement of magnets along the Z-axis
-Can use daisy chain connection mode to read multiple interconnected data in series
AS5040 device
-Wide temperature range: -40 ° C to+125 ° C
-Fully compliant with AEC-Q100, Level 1 specifications in the automotive industry
-Small lead-free package: SSOP 16 (5.3mm x 6.2mm)
1.3 Application
-Industrial applications:
-Contactless rotation position detection
-Robotics Technology
-Brushless DC motor commutation
-Electric tools
-Automotive applications:
-Steering wheel position detection
-Throttle position detection
-Transmission gearbox encoder
-Headlight position control
-Electric seat position indicator
-Office equipment: printers, scanners, copiers
-Replace optical encoders
-Front panel rotary switch
-Replace potentiometer
