Products Description
115 kW Excavating Machinery 15 Ton Mining Wheel Excavator SY80C
XE150WB wheeled hydraulic excavator is powerful, flexible and exquisite enough to cope with a variety of working conditions. The appearance size of the machine complies with road regulations and transportation requirements.
As a model featuring sufficient flexibility, high fuel efficiency and operation reliability in accordance with the North America
and Euro-III emission standards.
XE150WB plays an important role in the aspects of airport, port, oil field, urban construction, irrigation and water conservancy and rapid repair, and brings rich value returns for customers.
As a model featuring sufficient flexibility, high fuel efficiency and operation reliability in accordance with the North America
and Euro-III emission standards.
XE150WB plays an important role in the aspects of airport, port, oil field, urban construction, irrigation and water conservancy and rapid repair, and brings rich value returns for customers.
Product Paramenters
Engine model | / | QSB4.5 |
Output power of engine | Kw/r/min | 104/2000 |
Max.torque/engine | N.m | 586 |
Displacement | L | 4.5 |
Fuel tank capacity | L | 250 |
Rated flow of main pump | L/min | 2x160 |
Pressure of main safety valve | Mpa | 31.4/34.3 |
Hydraulic tank capacity | L | 135 |
Slewing speed | r/min | 13.7 |
Min.turning radius | mm | 6500 |
A Total length | mm | 6482 |
B Total width | mm | 2552 |
C Total heigth | mm | 3158 |
Min.ground clearance | mm | 359 |
Min.tail swing radius | mm | 2300 |
Wheelbase | mm | 2800 |
Track gauge | mm | 1920 |
Total width of chassis | mm | 2495 |
Distance between front axle and turning center | mm | 1700 |
Hood height | mm | 2430 |
The maximum digging depth of dozer | mm | 112 |
