Concrete Pump Diesel Engine Pump Electrical Delivery Pipe Motor Truck Mounted Concrete Pumping
- Category: >>>
- Supplier: Zhengzhou Wanshan Machinery Manufacturing Co. Ltd.
Share on (1601036054429):
Product Overview
Description
Product Description
Concrete Pump
The concrete pump also called concrete delivery pump which composed of a pump body and a delivery pipe. It is a machine that uses pressure to continuously transport concrete along pipelines. It is mainly used in construction of houses, bridges and tunnels. Mainly divided into gate valve concrete pump and S valve concrete pum
Structure
Product Details
Various Models
Model | xk-15A | ZS 23-B | ZS 30A-diesel |
Dimensions | 1.8*0.7*1.1M | 21m*0.7m*1.2m | 2.5m*1.2m*1.5m |
Power | 15kw | diesel 23kw | diesel 30kw |
Conveying particle size | <20mm | <20mm | <30mm |
Conveying height | 15-20m | 12-18m | 15-30m |
Horizontal transportation | 40-50m | 30-50m | 40-60m |
Pipe diameter | 80mm | 80mm | 80mm |
Efficiency | 6-8m³/h | 7-12m³/h | 8-14m³/h |
Weight |
| 900kg | 1100kg |
Model | ZS 35-diesel | ZS 40-diesel | ZS 50-diesel |
Dimensions | 3.2m*1.3m*1.6m | 3.8m*1.5m*1.8m | 4.2m*1.5m*1.5m |
Power | Diesel 4102 43kw | Diesel 4105 63kw | Diesel 4108 72kw |
Conveying particle size | <30mm | <30mm | <30mm |
Conveying height | 20-50m | 30-90m | 80-120m |
Horizontal transportation | 80-130m | 100-180m | 150-250m |
Pipe diameter | 8/10cm | 8/10cm | 8/10cm |
Efficiency | 10-16m³/h | 15-20m³/h | 18-25m3/h |
Weight | 1400kg | 1700kg | 2200kg |
Product Display
Packaging & Shipping
Company Information
