W Beam Road Guardrail Terminal End Galvanized Steel Safety Highway Steel Guardrail Highway Fence Safety Barrier
- Category: >>>
- Supplier: Shandong Essar Import And Export Trading Co. Ltd.
Share on (1601044717847):
Product Overview
Description
W Beam Road Guardrail Terminal End Galvanized Steel Safety Highway Steel Guardrail Highway Fence Safety Barrier
Highway/traffic guardrails have the advantages of good impact resistance, low cost, long life, higher safety, and environmental
protection. Uses: Expressway anti-collision facilities, isolation and other facilities.
protection. Uses: Expressway anti-collision facilities, isolation and other facilities.
1. The corrugated beam guardrail is the main form of the semi-rigid guardrail. It is a continuous structure that is spliced with corrugated steel guardrails and supported by columns.
2. It uses the deformation of soil foundation, columns and beams to absorb collision energy.
3. Corrugated beam guardrail is both soft and flexible.
2. It uses the deformation of soil foundation, columns and beams to absorb collision energy.
3. Corrugated beam guardrail is both soft and flexible.
PRODUCTION FLOW CHART
Specification
Product Name | Highway guardrail |
Normal Sizes | L:3200/3810/4000/4300/4320× W:306/310/312/380X Height : 80/82/83/85× Thickness :2.75/3/4mm. Available in different sizes. |
Profile | W beam , Thrie beam |
Surfacce treatment | Hot dipped galvanized or plastic sprayed coating |
Applicabele Standards | JT/T2811995(Corrugated Sheet Steel Beams For Expressway Guardrail - China), AASHTO M180(Corrugated Sheet Steel Beams For Highway Guardrail - USA), RAL RG620 (German) or any other International Standards |
Base Steel | Grade Q235B (equivalent to S235JR according to DIN EN 10025 and Gr. Daccording to ASTM A283M) or Q345 (S355JR / ASTM A529M 1994) |
The Thickness of Galvanized (Double Sides) | 550g/m2 (40µ) or 1100 g/m2 (80µ) or 1200 g/m2 (85µ) or as per your request |
Relevant Parts | Required for Guardrails Post, Spacer (C, U and Sigma types etc) and Fasteners, Bolts&Nuts,Terminal,Reflectors |
Product Advantages
First Advantage
Raw materials selected Q235 material,strong corrosion resistance, bright and beau-tiful, anti-collision strength are up to thestandards ofthe transportation department.
Secondary Advantage
Using flow impregnation process: uniformly coated polyethylene powder has strong adhesion,low temperature is not brittle,strong impact resistance and improves product service life
Third Advantage
The zinc layer is uniform and complete: after the hammer test,the zinc layer does not peel off,and after the neutral salt spray test for 200H,there is no corrosion phenomenon.
Company Profile
Shandong Essar is belongs to Shandong Essar Group which is located in beautiful Liaocheng City, Shandong Province of China.We mainly produce and supply hot dipped Galvanized steel coils,Galvalume coils,PPGI steel coils,Corrugated steel sheet and highway guardrail are widely applied to auto industry,household appliances,construction industry,and highway guardrail construction,etc.It specializes in manufacturing and selling hot dipped galvanized steel sheet/coil( annual 160,000 tons),corrugated steel sheet(annual 50,000 tons),and highway guardrail(annual 200,000 tons).The annual total sales is around RMB 1.85 billion Yuan,and the profit tax is around RMB 143 million Yuan.
The product performance index has achieved domestic advanced standard.and also has been exported to Mid-America,Africa,and Southeast Asia,etc.Total area of group is approximately 320 acres.
Holding to the intellectual businessman of style and the spirit of sincerity, all staff of our company are willing to cooperate and develop together with you。
Packing & Delivery
Customer Photos
Certifications
FAQ
Q:What about your price?
A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept the third party inspection absolutely.
Q:How about the delivery time?
A:Within 15-35 days after we confirm you requirement.
A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept the third party inspection absolutely.
Q:How about the delivery time?
A:Within 15-35 days after we confirm you requirement.
