Best quality used fuel oil tank semi trailer 4000 liters fuel tank trailers semi trailer
- Category: >>>
- Supplier: Shandong Tiantong Automotive Technology Co. Ltd.
Share on (1601075728748):
Product Overview
Description
Products Description
Factory Price Fuel tanker semi trailer Sale
The semi-trailer oil tank truck is divided into two parts, the oil tank part and the skeleton or driving part that supports the tank body,The rear of the semi-trailer oil tank truck is generally the same, with two rear axles or three rear axles, and the traction head can be selected according to the needs. Usually referred to as semi-trailer oil tank truck by the brand of the traction head Semi trailer oil tank truck tank body
1. The tank body is made of 4mm or 6mm high-quality carbon steel produced by a steel company and manufactured according to national standards. The shape of the tank body is divided into elliptical or square circular shapes, and it can hold 1-4 types of oil products. It can also produce heating and insulation series tank bodies.
2. Alcohol and chemical tankers are made of stainless steel imported from South Korea, with a thickness of 4mm-5mm.
3. Various types of hydrochloric acid, sulfuric acid, and alkaline tank trucks are made of plastic, with a thickness of 12mm to 22mm.
4. Multiple wave barriers are installed inside the tank. By using high-pressure gas leak testing, the tank body is characterized by high strength, stable center of gravity, and safe and stable vehicle transportation.
5. According to the purpose of the tanker, centrifugal pumps, gear pumps, and stainless steel pumps can be selected, which have the characteristics of large flow rate and fast suction speed.
6. Oil tank trucks can use single counting and double counting flow meters for metering, and can also be equipped with a tax controlled computer fuel dispenser, equipped with a 10-15 meter automatic retractable return reel, and equipped with a fuel gun. Edible oil can be measured using a computerized measuring instrument for edible oil.
1. The tank body is made of 4mm or 6mm high-quality carbon steel produced by a steel company and manufactured according to national standards. The shape of the tank body is divided into elliptical or square circular shapes, and it can hold 1-4 types of oil products. It can also produce heating and insulation series tank bodies.
2. Alcohol and chemical tankers are made of stainless steel imported from South Korea, with a thickness of 4mm-5mm.
3. Various types of hydrochloric acid, sulfuric acid, and alkaline tank trucks are made of plastic, with a thickness of 12mm to 22mm.
4. Multiple wave barriers are installed inside the tank. By using high-pressure gas leak testing, the tank body is characterized by high strength, stable center of gravity, and safe and stable vehicle transportation.
5. According to the purpose of the tanker, centrifugal pumps, gear pumps, and stainless steel pumps can be selected, which have the characteristics of large flow rate and fast suction speed.
6. Oil tank trucks can use single counting and double counting flow meters for metering, and can also be equipped with a tax controlled computer fuel dispenser, equipped with a 10-15 meter automatic retractable return reel, and equipped with a fuel gun. Edible oil can be measured using a computerized measuring instrument for edible oil.
We can customize according to customer needs.You can contact us for more detail.
Product Paramenters
Specifications of Fuel tanker semi trailer
Below are specifications for the main parts of the trailer.contact us for more details.
Fuel / Water Tank Truck Semi Trailer | ||||||||||
Dimension(Optional) | Axle No. | Rated Load (kg) | Tire No. | Tire Size | ||||||
10000-30000liters/10-30cbm | 2 | 40000 | 8 | 825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier) | ||||||
30000-60000liters/30-60cbm | 3 | 60000 | 12 | |||||||
Above 60000liters/60cbm | 4 | 75000 | 16 | |||||||
Wheel Base (mm) | 1310 | |||||||||
leaf-spring Pcs | 10 | |||||||||
Axle | 13/16/18 T | |||||||||
Suspension | Heavy Duty Mechanic Suspension with Leaf Springs | |||||||||
Main Beam Material | Q345B manganese plates, automatic submerged arc welded | |||||||||
Brake System | Dual line braking system with automatic braking system/chambers | |||||||||
Brake Air Chamber | Double Model | |||||||||
Kingpin | 2' or 3.5' Interchangeable | |||||||||
Landing gear | 28T loading capacity with 80T static lifting capacity. | |||||||||
Tanker body | 5mm , sealing end: 6mm | |||||||||
Brake System | Dual Lines Braking System With Automatic Air Chambers | |||||||||
Brake Air Chamber | Four double and two single chamber | |||||||||
Electrical System | 24V, 7core socket, lights according to European standards. | |||||||||
Mainbeam Size | Upper plate | 14mm | ||||||||
Lower plate | 16mm | |||||||||
Mid Web | 8 mm | |||||||||
Height | 500-520mm | |||||||||
Tool Box | 1 box of standard tools | |||||||||
Spare tire carrier | 2 sets | |||||||||
Color and Logo | Depends on the buyer’s requirement. | |||||||||
Pin Height | According to the height of the tractor saddle. | |||||||||
Painting | Three coats painting; Any color will be available | |||||||||
Manhole | 2pcs | |||||||||
Body Material | Carbon Steel/ Stainless Steel/Aluminium | |||||||||
Ladders | Steel with anti slipper walking way | |||||||||
Fire extinguisher | 2x 4kgs | |||||||||
handrail | Steel, manual | |||||||||
Application | For liquid transportation | |||||||||
Packing and delivery
Paking:product naking
Shipping:shipment by sea or land.
Company Profile
Shandong TianTong Automotive Technology Co.,Ltd. Was established on July 29,2008.It is a production enter-prise with proprietary rights in the production of road motor vehicles,research and development,manufacturing and sales of automotive parts,and sales of new energy vehicles.We provide product design based on customer needs,providing customers with convenient,safe,and environmentally friendly products.High quality provides customers with the greatest guarantee,allowing them to experience more efficient value.We sincerely look forward to working with you.
We are manufacturer and our company has long history experiences of industry for many years.Our factory is located in shandong province,China.It has large square and we have many special engineers to produce the good
goods according to the customers’ needs.By technology development more and more,we could produce many styles of semi-trailer equipments,such as flatbed semi-trailer,low bed semi-trailer,sidewall semi-trailer,tipper semi-trailer,rear dump semi-trailer,bulk cement semi-trailer,cargo fence semi-trailer,side lifter -semi-trailer,skeleton semi-trailer and car carriage semi-trailer etc.Our semi-trailerequipments have a wide variety with high quality,they have generous appearance and resonable structure.We use high-quality materials and advance production processes to ensure that producing stable system and good production.We can also allowed to customize according to customers’ requirements and needs. If you are interesting in our products,please contact us!Look forward to your inquiry!
goods according to the customers’ needs.By technology development more and more,we could produce many styles of semi-trailer equipments,such as flatbed semi-trailer,low bed semi-trailer,sidewall semi-trailer,tipper semi-trailer,rear dump semi-trailer,bulk cement semi-trailer,cargo fence semi-trailer,side lifter -semi-trailer,skeleton semi-trailer and car carriage semi-trailer etc.Our semi-trailerequipments have a wide variety with high quality,they have generous appearance and resonable structure.We use high-quality materials and advance production processes to ensure that producing stable system and good production.We can also allowed to customize according to customers’ requirements and needs. If you are interesting in our products,please contact us!Look forward to your inquiry!
Certifications
We have many certifications for our company or our products.
Service
1. We can provide consultation sevice online of products for 24-hours when you are interesting in our products before buy our products or after purchase our products.
2. We can provide the draw of semi-trailer equipment and make the good measure to meet our needs.
3. We can provide the the technical guidance and we will establish a comprehensive customers receive timely and professional service support after you purchase our produts.
4. We are manufacuturer of semi-trailer and we can give you the competitive price of semi-trailer.
5. We can accept the customization in order to meet the various custemers’
2. We can provide the draw of semi-trailer equipment and make the good measure to meet our needs.
3. We can provide the the technical guidance and we will establish a comprehensive customers receive timely and professional service support after you purchase our produts.
4. We are manufacuturer of semi-trailer and we can give you the competitive price of semi-trailer.
5. We can accept the customization in order to meet the various custemers’
FAQ
Q1. Can i paint my logo on trailer?
A:Sure,you can send us your company logo,and we will help you put onto the semi-trailer.
Q2. Which terms of delivery do you support?
A:EXW,FOB,CFR,CIF and we will have a negotiation with our cunstomers before signed the sales contract and according to the customers requirements choose the suitable method.
Q3. Which payment terms do you have ?
A:Normally,We are surpported 100% T/T before shipment ,L/C at sight,if you have other requirements of payment we hope that have a negotiation with us.
Q4. Are you manufacturer or trade company?
A:We are manufacture of semi-trailer and we have our own factory and many engineers .
A:Sure,you can send us your company logo,and we will help you put onto the semi-trailer.
Q2. Which terms of delivery do you support?
A:EXW,FOB,CFR,CIF and we will have a negotiation with our cunstomers before signed the sales contract and according to the customers requirements choose the suitable method.
Q3. Which payment terms do you have ?
A:Normally,We are surpported 100% T/T before shipment ,L/C at sight,if you have other requirements of payment we hope that have a negotiation with us.
Q4. Are you manufacturer or trade company?
A:We are manufacture of semi-trailer and we have our own factory and many engineers .
