Liugong Brand Large Digger Clg970e 70500kg Mining Crawler Excavator
- Category: >>>
- Supplier: Sinomada Heavy Industry (Changsha) Co. Ltd.
Share on (1601110568469):
Product Overview
Description
Sinomada
Contact Way
Frances Liao
Email: frances@sinomada.com
Whatsapp/skype/Wechat: 86 18273188304
Product Overview
Liugong CLG970E 70 ton Mining Crawler Excavator
The 970E is powered by the latest Cum-mins QSX15 engine with a rated net power of 357 kW (479 hp) @ 1800 rpm in compliance with EU Stage IIIA emission standards.
Heavy duty undercarriage components, reinforced idler frame and optional full track guard guarantee the integrity of our
undercarriage.
ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System) safeguard your operator in the toughest
environment.
Visibility is key to protecting your operator and workers on site. The large glass surface area, spacious cab, combined with the
rear-view camera, provides an extraordinary view of the 970E's surroundings.
Product parameters
Operating Weight | 70,500 kg |
Bucket Capacity | 4.0 - 4.3 m³ |
Engine | Cum/mins QSX15 |
Gross Power | 373 kW (508 hp) @ 1,800 rpm |
Net Power | 357 kW (485 hp) @ 1,800 rpm |
Peak Torque | 2,363 N•m @ 1,400 rpm |
Travel Speed | High:4.4 km/h Low: 2.7 km/h |
Drawbar Pull | 460 kN |
Swing Speed | 6.8 rpm |
Arm Breakout Force, max, ISO | 327 kN |
Bucket Breakout Force, max, ISO | 376 kN |
Maximum Dig Depth | 7,180 mm |
Reach at Ground Level | 11,170 mm |
Depth of 8' Level Bottom | 7,030 mm |
Maximum Dig Height | 10,950 mm |
Dump Height | 7,030 mm |
Maximum Dig Depth of Vertical Wall | 4,070 mm |
Overall Lenth | 12,230 mm |
Overall Width | 4,260 mm |
Overall Height | 4,710 mm |
