Dual Port 10GBASE T Ethernet PCI Express 3.0 x8 OCP 3.0 Small FormFactor Card Broadcom 57416 BCM957416N4160C OCP Network Adapter
- Category: >>>
- Supplier: JLS Future Trading Limited
Share on (1601201230022):
Product Overview
Description
Products Description
BCM957416N4160C Dual-Port 10GBASE-T Ethernet PCI Express 3.0 x8 OCP 3.0 Small-FormFactor Card
The Broadcom® BCM957416N4160C is a dual-port 10 Gb/s PCI Express 3.0 x8 Network Adapter Card designed to the Open Compute Project (OCP) 3.0 Design Specification in small form factor with two 10GBASE-T network connectors. The adapter supports 10GBASE-T and 1000BASE-T Ethernet on Category 6, 6A, or 7 twisted-pair cables. The 1000BASE-T can operate on standard Category 5e UTP. The card uses the Broadcom BCM57416 10GBASE-T controller
Specification
* Model: BCM57416 |
* Compliant Standards: OCP 3.0 |
* Connectivity Technology: Wired |
* Data Link Protocols: 10 Gigabit Ethernet |
* Data Transfer Rate: 10 GBps |
* Form Factor: Plug-in card |
* Host Interface: Open Compute Project mezzanine (OCP) 3.0 |
* PCI Specification Revision: PCIe 3.0 |
* Product Type: Network adapter |
* Interface Provided: 2 x 10Gb Ethernet |
* Network & Adapter Ports: 1/2.5/5/10GBase-T |
