Factory Intel Gemini Lake R J4125 Firewall Motherboard Router 4 lan Port USB3.0 RS232 RS485 4K Display Nano Itx Motherboard
- Category: >>>
- Supplier: Shenzhen Zunsia Intelligent Technology Co. Ltd.
Share on (1601205288803):
Product Overview
Description
Ordering informatioon
processor system | Onboard Intel Gemini Lake/Gemini Lake-R series single-chip CPU, J4105/J4125 |
EFI BIOS | |
Memory | Onboard LPDDR4 memory particles, optional 4GB/8GB |
storage | 1 SATA3.0 storage interface + 2pin SATA power supply |
1 mSATA interface | |
Optional onboard eMMc, optional 64GB/128GB/256GB | |
display | 1 HDMl2.0 interface, support 4096x2160@60HZ; 1 VGA interface, 1 internal VGA pin |
0n-board l/0interface | 1 DC Jack power connector |
1 HDMl display interface | |
4 RJ45 2.5G network ports | |
2 USB3.0 ports | |
1 VGA | |
1 reset button, 1 power button | |
Extendedinterface/function | With TPM2.0, optional, no default |
1 MiniPcle (usB2.0 protocol, support WlFl/3G/4G module); 1 SlM card slot | |
1 F_Panel, 2x5PlN, pitch 2.0mm | |
1 2PIN Phoenix terminal power port, optional 4Pin ATX power port | |
1 inner VGA pin header,2x5PlN, pitch 2.0mm | |
1 serial port pin header 1x3PiN, spacing 2.54mm, default RS232, optional RS485 | |
1 4-bit GPl0 pin header, 2x3PIN, pitch 2.0mm | |
AT/ATX power-on mode optional | |
1 LED holder (2LED);1 buzzer | |
Watchdog:0-255sec | |
No fan by default, optional fan | |
0s support | Windows10.windows11, Linux |
size | 120x120mm |
net weight | 220g with radiator, 130g without radiator |
