The Brand Of Longhua Horizontal Cold Chamber Die casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy
The Brand Of Longhua Horizontal Cold Chamber Die-casting Machine Is Trustworthy

The Brand Of Longhua Horizontal Cold Chamber Die casting Machine Is Trustworthy

Share on (1601205872816):


Price:$10,000.00 - $10,500.00

Quantity:


Product Overview

Description







ITEMS
Unit
Specification
Clamping Force
KN
1400
Opening stroke
mm
350
Die thickness(Min--Max)
mm
200～500
Space between tie bars
mm
420*420
Ejector stroke
mm
80
Ejector force
KN
100
Injection position（0 as center）
mm
0，-100
Injection force（intensification)
KN
180
Injection stroke
mm
320
Plunger diameter
mm
￠40 ￠50 ￠60
lnjection weight(aluminum)
Kg
1.3
Casting pressure (intensification)
MPa
143/92/64
Max. casting area(40Mpa)
CM2
350
Injection plunger penetration
mm
120
Diameter of pressure chamber flange
mm
110
Height of pressure chamber flange
mm
10
Max.working pressure
MPa
12
Motor power
Kw
11
Dimensions (L*W*H)
m
4.6*1.2*1.5
Machine lifting reference weight
T
4.5
Oil tank capacity
L
300




FAQ


1. Who are we?
We are based in Anhui, China, start from 2014,sell to Domestic Market(50.00%),Southeast Asia(15.00%),South Asia(12.00%),South America(8.00%),Eastern Asia(8.00%),Africa(5.00%),Mid East(2.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Die Casting Machine/Robot For Die Casting Machine,Compressor,Die Casting Machine Parts,Mould And Castings,Melting Furnace

4. Why should you buy from us not from other suppliers?
Longhua Die Casting Machine has 39 years of production experience, and cooperate with the Chinese Academy of Science and Technology, you know that China's space shuttles are cooperating with the Chinese Academy of Science and Technology.

5. What services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
