DSE501K Generator Controller Unit DSE501K Manual Key Start Control Panel Replace for Original Engine Control Module DSE501
- Category: >>>
- Supplier: Fuzhou Leeds Electric Co. Ltd.
Share on (1601206808538):
Product Overview
Description
Products Description
Model Number： | DSE501K | Weight： | 1KG |
Stock： | 1000pcs | Brand Name： | Deep Sea |
Color： | Black | Place of Origin： | Fujian, China |
Quality： | High-Quality | Warranty： | 3months-1year |
Description
The Model 501K-1 is a Manual Engine Control Module, which has been designed to manually control the engine via a key switch on the
front panel. The module is used to start and stop the engine, indicating fault conditions; automatically shutting down the engine
and indicating the engine failure by LED giving true first up fault annunciation.
Specification
DC Supply：9~33V continuous.
Alternator Input Range：15~305V AC RMS
Alternator Input Frequency：50~60Hz at rated engine speed.
Magnetic Input Range：0.5V~+/-80V
Magnetic Input Frequency：2300Hz~6000Hz
Start Relay Output：16 Amp DC at supply voltage
Run Relay Output：16 Amp DC at supply voltage
Alarm Output：1Amp DC at supply voltage
Operating Temperature Range： -30~70celsius
front panel. The module is used to start and stop the engine, indicating fault conditions; automatically shutting down the engine
and indicating the engine failure by LED giving true first up fault annunciation.
Specification
DC Supply：9~33V continuous.
Alternator Input Range：15~305V AC RMS
Alternator Input Frequency：50~60Hz at rated engine speed.
Magnetic Input Range：0.5V~+/-80V
Magnetic Input Frequency：2300Hz~6000Hz
Start Relay Output：16 Amp DC at supply voltage
Run Relay Output：16 Amp DC at supply voltage
Alarm Output：1Amp DC at supply voltage
Operating Temperature Range： -30~70celsius
Product Categories
Company Profile
Company Profile
Fuzhou Leeds Electric Co, Ltd is located in Fuzhou, Fujian, China. lt is aprivate manu facture of generator owning its on-line and off-line sales system.
Leeds mainly produces gen-sets from 10KW to 2000KW and Generator accessories.All generator typesand various brandsof enaines (CUMMNS,VMAN.SHANGCHALYANGDONGECT) are available here,in order to match with different requests and tasteof our customers.
Production Process
Product packaging
FAQ
Q1: What is your MOQ of this item?
A: 1 pcs
Q2: Are the products original ?
A: Most of the products are manufactured by us because we are manufacturers, but can 100% replaced the original one with reliable performance. Also we supply the Original parts for the parts too.Welcome to inquiry
Q3: What' s the warranty?
A: The general warranty is 12 months, long-term customers can apply for a longer warranty
