High efficient Gree GMV5 DC Inverter Commercial Multi VRF System Central Air Conditioners Heat Pumps
- Category: >>>
- Supplier: Beijing Jiayi Jiaxin Technology And Trade Co. Ltd.Beijing Ltd.
Share on (1601213129641):
Product Overview
Description
Product Description
GMV5 Heat Pump
ODU 208/230V | ODU 460V | ODU Combination 208/230V | ODU Combination 460V
(ODU=Condensing Unit)
Gree Air Cooled GMV5 All DC Inverter VRF adopts high-efficient DC inverter compressor and DC inverter fan motor. The unit can be combined modularly from 6 Ton to 30Ton. Maximum capacity can up to 360 kBtu/h.
* Outdoor unit quiet mode.
* High energy efficiency with high-performance compressor; Long connection pipe design with the maximum length of 3280 3/4 feet.
* Auto switch of module status in every 8hrs, which greatly improves the reliability of complete unit.
* 4 levels of static pressure for option with the maximum of 0.33In.W.G.
ODU 208/230V | ODU 460V | ODU Combination 208/230V | ODU Combination 460V
(ODU=Condensing Unit)
Gree Air Cooled GMV5 All DC Inverter VRF adopts high-efficient DC inverter compressor and DC inverter fan motor. The unit can be combined modularly from 6 Ton to 30Ton. Maximum capacity can up to 360 kBtu/h.
* Outdoor unit quiet mode.
* High energy efficiency with high-performance compressor; Long connection pipe design with the maximum length of 3280 3/4 feet.
* Auto switch of module status in every 8hrs, which greatly improves the reliability of complete unit.
* 4 levels of static pressure for option with the maximum of 0.33In.W.G.
Product Paramenters
Model | - | GMV-224 WM/B-F | GMV-280 WM/B-F | GMV-335 WM/B-F | GMV-400 WM/B-F | GMV-450 WM/B-F | GMV-504 WM/B-F1 | GMV-560 WM/B-F1 | ||||||||||||
GMV-615 WM/B-F1 | Capacity range | HP | 8 | 10 | 12 | 14 | 16 | 18 | ||||||||||||
20 | 22 | Capacity | Cooling | kW | 22.4 | 28 | 33.5 | 40 | 45 | |||||||||||
50.4 | 56 | 61.5 | Heating | kW | 25 | 31.5 | 37.5 | 45 | ||||||||||||
50 | 56 | 63 | 69 | EER | kW/kW | 4.31 | 4 | 3.98 | ||||||||||||
3.76 | 3.56 | 3.38 | 2.97 | 2.75 | COP | kW/kW | 4.55 | 4.32 | ||||||||||||
4.17 | 4.05 | 3.85 | 3.84 | 3.6 | 3.16 | Power supply | Cooling | V/Ph/Hz | 208/230V-3Ph-60Hz | |||||||||||
MCA | A | |||||||||||||||||||
36 | 38 | 43 | 60 | 65 | 68 | 74 | 80 | MOP | ||||||||||||
A | 60 | 60 | 60 | 80 | 90 | 93 | 103 | 112 | Power | |||||||||||
Cooling | kW | 5.2 | 7 | 8.41 | 10£5 | 12.65 | 14.9 | 18.9 | 22.3 | |||||||||||
comsumption | Heating | kW | 5.5 | 7.3 | 9.0 | 11.1 | 13 | 14.6 | 17.5 | |||||||||||
21.8 | Maximum drive IDU NO. | unit | 13 | 16 | 19 | 23 | 26 | 31 | ||||||||||||
34 | 38 | Refrigerant Charge volume | kg | 5.9 | 6.7 | 8.2 | 9.8 | 10.3 | ||||||||||||
12.7 | 13 | 13.5 | Sound pressure level | dB(A) | 60 | 61 | 63 | 63 | ||||||||||||
63 | 65 | 66 | 66 | Connecting | Liquid | mm | ||||||||||||||
Pipe | Gas | mm | ||||||||||||||||||
Oil balance | mm | |||||||||||||||||||
Dimension | Outline | mm | ||||||||||||||||||
930*765*1605 | 1340*765*1605 | 1340*765*1740 | (W*D*H) | Package | ||||||||||||||||
mm | 1010*840*1775 | 1420*840*1775 | 1420*840*1910 | Net weight/Gross weight | ||||||||||||||||
kg | 225/235 | 225/235 | 285/300 | 360/375 | 360/375 | 400/415 | 400/415 | 400/415 | ||||||||||||
