Products Description
RP453 4m Asphalt Finisher Paver Concrete with Automatic Controler
1. Basic paving width: 2.5 meters
2. Max. paving width: 7.25 meters
3. Max. paving thickness: 300 mm
4. Cummmmmins QSB6.7-C170 129kW
2. Max. paving width: 7.25 meters
3. Max. paving thickness: 300 mm
4. Cummmmmins QSB6.7-C170 129kW
RP603 paver can be applied in the construction work of highway asphalt pavement of various grades for paving different types and gradations of asphalt concrete materials. Due to electric heating hydraulic telescopic screed, it is especially suitable for urban construction, municipal maintenance and other projects. The machine incorporates full hydraulic drive and micro- computer control, realizing automatic control of material level and leveling. High level of automation in combination with the new generation ergonomic operation platform, providing more simple, faster operation experience.
* The control mode is upgraded to mature CAN communication, intelligent paving management function allowing real-time monitoring and automatic fault diagnosis of the whole vehicle.
* The walking control utilizes the technology of constant speed automatic control to avoid the paving speed affected by load.
* Ultrasonic automatic control technology is adopted to control the material level. The material level can be controlled stably and the auger speed can be adjusted continuously.
* Digital automatic leveling technology ensures high evenness, filling the requirements of high-grade road construction.
* The control mode is upgraded to mature CAN communication, intelligent paving management function allowing real-time monitoring and automatic fault diagnosis of the whole vehicle.
* The walking control utilizes the technology of constant speed automatic control to avoid the paving speed affected by load.
* Ultrasonic automatic control technology is adopted to control the material level. The material level can be controlled stably and the auger speed can be adjusted continuously.
* Digital automatic leveling technology ensures high evenness, filling the requirements of high-grade road construction.
Product Paramenters
ltem | Unit | RP603 | ||
Basic Pave Width | m | 2.5~4.75 | ||
Maximum Pave Width | m | 6 | ||
Maximum Layer Thickness | mm | 350 | ||
Maximum Paving Speed | m/min | 20 | ||
Maximum Travel Speed | km/h | 3 | ||
Hopper Capacity | t | 14 | ||
Maximum Laydown Rate | t/h | 400 | ||
Engine and Type | - | QSB6.7-C170 | ||
Rated Power | kW/rpm | 129/2200 | ||
Shipping Dimension (LxWxH) | mm | 6680*2500*3180 | ||
Shipping Weight | t | 18.5 | ||
Full Dimension (LxWxH) | mm | 6680*2500*4000 | ||
Full Weight | t | 19 | ||
Heating of screed | - | Electric/Gas heating | ||
Travel type | - | tire | ||
Wheel Base | mm | 1600 | ||
Tread(fwd/bwd) | mm | 970/970 | ||
Overhand(fwd/bwd) | mm | 477/515 | ||
Min.Under clearance | mm | 110 | ||
Lateral Fork Adjustment(Outside of Forks) | mm | 1030/244 | ||
Fork Length | mm | 1070 | ||
Fork Width/Thickness | mm | 122/40 | ||
Performance Parameter | ||||
Lifting speed(Loaded) | mm/s | 550 | ||
Lowing speed(Loaded) | mm/s | 450 | ||
Traveling speed(Unloaded/Loaded) | km/h | 17/19 | ||
Max.Gradeability(Unloaded/Loaded) | % | 21.5/17 | ||
Weight | kg | 3800 | ||
