Compact XE60WGA 6 Ton Excavator Featuring a 0.21 Cubic Meter Bucket
- Category: >>>
- Supplier: Richmchn Machinery Engineering (Shanghai) Co. Ltd.
Share on (1601270485544):
Product Overview
Description
6 Ton Wheeled Excavator XE60WGA For Sale
Contact Way
Rita Li - Sales Manager
Tel: +86-158-2177-7011
Whatsapp/Wechat/Mobile: +86-158-2177-7011
Email: rita@richmchn.com
Product Overview
6Ton 0.21cbm Wheel Excavator XE60WGA
* Operating weight: 5900kg
* Bucket capacity: 0.21m³
High Performance and Highlights
1. Equipped with imported engine, meeting the National IV emission standards, it is economical and environmentally friendly, and the product dimensions comply with road regulations and transportation requirements, making it easier to transfer between sites;2. The cab complies with ROPS certification. It comes standard with a rear camera and various work lights, reflectors, etc. to eliminate blind spots in the field of vision during operation and driving. It is safe and guaranteed. It is equipped with a new air conditioner, with stronger cooling and heating capabilities and less noise. The design of large wrapped seats and integrated armrest box relieves work fatigue and improves long-term working comfort;
3. Optimize engine transient response performance, perfectly match the hydraulic system, and achieve the best balance of high efficiency and low fuel consumption in the low-speed working area. The vehicle's forward, neutral, reverse and high/low gears are located on the right joystick, which conforms to road equipment operating habits and has cruise and slow-motion functions;
4. All parameters of the whole machine have been strictly assessed and measured to ensure the reliability and stability of the product. Ultra-long maintenance cycle and ground-accessible maintenance are convenient and fast, saving time and worry;
5. The product comes standard with a breaker pipeline and a dozer blade, and can be optionally equipped with a multi-functional tool system, quick changer and front outriggers, which can meet the needs of different operations such as excavation, crushing, grabbing, shearing, and pushing.
Product Parameters
Model | Unit | XE60WA | ||
Operating weight | Kg | 5900 | ||
Bucket capacity | m³ | 0.23 | ||
Engine | Model | / | Yan--mar | |
4TNV98 | ||||
No.of cylinders | / | 4 | ||
Rated power/speed | kw/rpm | 42.5/2400 | ||
Maxium Torque/swing speed | N.m | 201/1800 | ||
Displacement | L | 3.319 | ||
Main performance | Travel speed(H/L) | km/h | 30/10.5 | |
Swing speed | r/min | 10 | ||
Gradeability | ° | ≤30 | ||
Bucket digging force | kN | 42.8 | ||
Arm digging force | kN | 25.8 | ||
Hydraulic System | Main pump | / | 150 | |
Rated flow | L/min | 150 | ||
Main safety valve pressure | MPa | 22 | ||
Travel system pressure | MPa | 22 | ||
Swing system pressure | MPa | 22 | ||
Pilot system pressure | MPa | 3 | ||
Oil Capacity | Fuel tank capacity | L | 110 | |
Hydraulic tank capacity | L | 120 | ||
Engine oil capacity | L | 7 | ||
Appearance size | Total length | mm | 6230 | |
Total width | mm | 1925 | ||
Total height | mm | 2850 | ||
Width of platform | mm | 1845 | ||
Total width of chassis | mm | 1925 | ||
Counterweight clearance | mm | 970 | ||
Working scope | Max. digging height | mm | 5830 | |
Max. dumping height | mm | 4240 | ||
Max. digging depth | mm | 3520 | ||
Max. vertical wall digging depth | mm | 2400 | ||
Max. digging radius | mm | 6120 | ||
Min. swing radius | mm | 2510 | ||
Standard | Boom Length | mm | 3000 | |
Arm Length | mm | 1600 | ||
Bucket Capacity | m³ | 0.23 | ||
