Casing Scraper specification

Product Overview

Description

oil tools Casing Scraper

 Casingscraper is ideal for the removal of dirt which may be left over the inside walls of casing, such as solid cement, hard wax, various salt crystals or deposits, perforation burrs, iron oxide residues resulted from rusting, so as to make all down hole tools pass through unblocked. Especially when a small circular clearance is available between the down hole tools and casing inside diameter, the complete scrapping becomes more necessary before further working. At present in thelarge petroleum well scrapping in the internal wall of casing by use of casing scraper is a necessary step.



Model	Max. O.D. of blade strech out (mm)	Min. O.D. of blade strech out (mm)	Connection	Casing Size (in)
GX114	106	95	NC26	4 1/2
GX127	118	105	NC26	5
GX140	130	117	NC31	5 1/2
GX168	158	141	3 1/2 REG	6 5/8
GX178	166	149	3 1/2 REG	7
GX245	230	212	4 1/2 REG	5/8





 5) Company Information:



Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.



We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.



Our  products mainly include:

1. Pumping Unit                       2. Tubing Pump/Sucker Rod Pump and Accessories

3. Float Collar & Float Shoe    4. Casing Centralizer
5. Cementing Plug                  6. Cementing Head
7. Stage Collar                        8. Casing/Tubing and Coupling
9. Drill Pipe                            10. Sucker Rod
11. Air Blaster                         12. Sucker Rod Guide
