Drick Brand Mini Tensile Tester Single Column Computerized Electronic Tensile Testing Machine Stretch Test Machine
- Category: >>>
- Supplier: Shandong Drick Instruments Co. Ltd.
Share on (1601272659906):
Product Overview
Description
Product Description
DRK101 Tensile Test Machine
DRK101 Tensile testing machine is designed and according to the international Method for the determination of different materials tensile strength (constant rate of loading method).
Applicable in Paper, cardboard, plastic film, composite film, flexible packaging materials, adhesive, adhesive tape, adhesive, rubber, paper, plastic aluminum plate, paint, fabric, textile, waterproof material, triangle belt180 degree peel, 90 degrees peel strength, elongation, fixed length force experiment.
Applicable in Paper, cardboard, plastic film, composite film, flexible packaging materials, adhesive, adhesive tape, adhesive, rubber, paper, plastic aluminum plate, paint, fabric, textile, waterproof material, triangle belt180 degree peel, 90 degrees peel strength, elongation, fixed length force experiment.
Product features:
1, automatic shutdown: after the sample is broken, the moving beam will automatically stop and automatically reset;
2, double screen display, convenient and practical, easy to save data.
3, conditional storage: test control data and sample conditions can be made into modules, which facilitates the batch test;
4, automatic saving: after the test, the test data and curves are automatically saved;
5, process realization: the test process, measurement, display and analysis are completed by the microcomputer;
6, batch test: for the same parameters of the sample, once set can be completed in sequence;
7. Test software: Chinese and English WINDOWS interface, menu prompt;
8, display mode: data and curves with the test process dynamic display;
9, curve traversal: after the test is completed, the curve can be re-analyzed, and the test data corresponding to any point of the curve can be found with the mouse;
10, curve selection: according to the need to select stress-strain, force-displacement, force-time, displacement-time and other curves for display and printing;
11. Test report: Report can be prepared and printed in the format required by users;
12, limit protection, overload protection, automatic stop;
13, automatically obtain the test results, automatically form a report, so that the data analysis process is simple.
2, double screen display, convenient and practical, easy to save data.
3, conditional storage: test control data and sample conditions can be made into modules, which facilitates the batch test;
4, automatic saving: after the test, the test data and curves are automatically saved;
5, process realization: the test process, measurement, display and analysis are completed by the microcomputer;
6, batch test: for the same parameters of the sample, once set can be completed in sequence;
7. Test software: Chinese and English WINDOWS interface, menu prompt;
8, display mode: data and curves with the test process dynamic display;
9, curve traversal: after the test is completed, the curve can be re-analyzed, and the test data corresponding to any point of the curve can be found with the mouse;
10, curve selection: according to the need to select stress-strain, force-displacement, force-time, displacement-time and other curves for display and printing;
11. Test report: Report can be prepared and printed in the format required by users;
12, limit protection, overload protection, automatic stop;
13, automatically obtain the test results, automatically form a report, so that the data analysis process is simple.
Specifications | 500N standard, 50N, 100N, 500N, 1000N (optional) | |||||
accuracy | better than 1 level | |||||
force value resolution | 0.1N | |||||
Displacement resolution | 0.001mm | |||||
test speed | 0.01mm/min ~ 2000mm/min (adjustable) | |||||
sample width | 30mm standard (optional) | |||||
sample clamping | manual (can change the pneumatic clamping) | |||||
travel | 700mm standard, 400mm, 1000mm (optional) | |||||
