Basket mill FTM 350 Ex proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery
Basket mill FTM 350 Ex-proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery

Basket mill FTM 350 Ex proof hydraulic basket mill paint grinding machine tile adhesive mixer machinery

Share on (1601274955433):


Price:$8,750.00 - $9,500.00

Quantity:


Product Overview

Description





Characteristics
- Suits for producing small batch product and middle test. Dispersing and grinding are finished in one machine and one
container, no need extra pumps, piping, valves etc.
- Easy cleaning, no residues, convenient product replacement.
- Little grinding media required. Excellent grinding efficience and effect.
- Double-walled container for colling and heating.
- Modular desigin of parts make it muchi more convenient to disassemble, maintain and overhaul, almost no need of
professional mantainer.


Principle
The milling basket, containing the grinding bead is lowered into the mill base; the fast circulation of the mill base within the milling basket is generated by the dispersing disc and integrated pump wheel, and a very narrow particle size distribution can be achieved very quickly.


Parameter


type/parameter
motor power Kw
voltage V
speed rpm
handling capcity L
basket
capacity L
lifting height
mm
milling medium mm
overall size mm L*W*H
FTM50
2.2
~380
0-1500
10-50
1
400
1.8-2.0
1700*800*1500
FTM100
4
~380
0-1500
30-100
2
500
1.8-2.0
1700*800*1500
FTM200
7.5
~380
0-1500
50-200
4
600
1.8-2.0
2100*900*1900
FTM250
11
~380
0-1500
80-250
6
700
1.8-2.0
2100*900*1900
FTM350
15
~380
0-1500
150-350
10
800
2.0-2.4
2350*1050*1900
FTM500
18.5
~380
0-1500
200-500
16
900
2.0-2.4
2350*1050*1900
FTM1000
22
~380
0-1500
400-800
20
1000
2.0-2.4
2400*1100*2100
FTM1500
30
~380
0-1500
800-1200
30
1100
2.0-2.4
2500*1300*2300
FTM2000
45
~380
0-1000
1000-2000
70
1300
2.0-2.4
2800*1300*2400
FTM3000
55
~380
0-1000
1000-3000
100
1500
2.0-2.4
3000*1400*2600
FTM3500
75
~380
0-1000
1000-3500
180
1600
2.0-2.4
3100*1500*2800
