Items | Lowbed semi trailer QUEST - S40 | Lowbed semi trailer QUEST - S70 | |||
Loading Capacity | 30-40 tons | 60-80 tons | |||
Axle | 2/3 pieces, FUWA/BPW axle | 4 pieces, 13T FUWA/BPW axle | |||
Tyre | 8 /12pieces, 235/70R17.5/8.25R20 | 16 pieces, 10.00R20/11.00R20 | |||
Dimensions(LxWxH) | 12500 to 16000mm x 3000 x 1550mm | ||||
Tare weight | 5.5 tons to 8 tons | ||||
Axle spacing | 1310mm | ||||
Rims | 8.5-20, 9.0-20 | ||||
Suspension System | Leaf spring suspension / air suspension | ||||
Brake System | Dual line pneumatic brake system with WABCO emergency relay valve | ||||
Main Beam | Height 500mm Q345 | ||||
Chassis | upper 20mm, lower 20mm. Mid web 12mm | ||||
Ramp | 1 pair of heavy duty ramp(leaf spring type or hydrualic ramp optional) | ||||
Kingpin | 2’ or 3.5’ interchangeable | ||||
Landing Gear | 28 Tons , Two speed manual operation | ||||
Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard | ||||
Lights and Reflectors | Rear light, rear reflector, turn indicative light, side reflector,fog lamp, number plate light | ||||
Painting | Shot blast to SA 2.5 Standard prior to application of primer,polyurethane top coat. Total DFT not less than 100μm;Any color will be available | ||||
Tool Box | One tool box with a set of standard trailer tools | ||||
Spare Tyre Carrier | One piece or two pieces |
