2024 Hot Sale XQ114/6B 2 7/8 3 1/2 4 1/2 Hydraulic Power Tong For well service
- Category: >>>
- Supplier: Puyang Baolitong Petroleum Machinery Co. Ltd.Puyang Ltd.
Share on (1601297001523):
Product Overview
Description
Products Description
Teda XQ140/12A Hydraulic Power Tong
This tong has the following featurers:
****It is Used for quick make-up/break-out tube in well service operations.
****It is mainly made up of two parts, master tong and backup tong.
**** Range of master tong is 73-140mm(2-7/8-5-1/2 inch)
****Range of backup tong is 73-156mm(2-7/8-8-1/8 inch)
****High Gear Rated of Torque: 2600 N.m (1900 ft-ibs)
****Low Gear Rated of Torque: 12000 N.m (8850 ft-ibs)
****It is Used for quick make-up/break-out tube in well service operations.
****It is mainly made up of two parts, master tong and backup tong.
**** Range of master tong is 73-140mm(2-7/8-5-1/2 inch)
****Range of backup tong is 73-156mm(2-7/8-8-1/8 inch)
****High Gear Rated of Torque: 2600 N.m (1900 ft-ibs)
****Low Gear Rated of Torque: 12000 N.m (8850 ft-ibs)
Model | X089/3YC | XQ114/6YB | XQ140/12A | XQ140/20 | XQ140/30 | XQ194/40 | ||
mm | 60-89 | 60-114 | 73-140 | 42-140 | 42-140 | 42-194 | ||
Applicable range main tong | in | 23/8~31/2 | 23/9~41/2 | 27/8~51/2 | 1.66~51/2 | 1.66~51/2 | 23/8~75/8 | |
mm | 60-114 | 73-141.5 | 89-156 | 60-153.7 | 60-153.7 | 60-215.9 | ||
Applicable range backup tong | in | 23/8~41/2 | 27/8~51/8 | 31/2~61/8 | 23/8~6.05 | 23/8~6.05 | 23/8~81/2 | |
N.m | 3300 | 6000 | 12000 | 20000 | 30000 | 40000 | ||
Max.torque | ft.lbf | 2213 | 4425 | 8850 | 15000 | 22500 | 30000 | |
Speed | rpm | 30-90 | 20-85 | 14-72 | 13.5-58 | 9-40 | 5.9-25 | |
Rated pressure | Mpa | 10 | 11 | 12 | 17.5 | 17.5 | 17.5 | |
psi | 1450 | 1595 | 1740 | 2500 | 2500 | |||
Max.oil supply | L/min | 80 | 100 | 120 | 140 | 140 | 140 | |
gpm | 21 | 26 | 32 | 38 | 38 | 38 | ||
size | mm | 650*430*550 | 750*500*600 | 1024*582*539 | 1115*962*1665 | 1180*1000*1665 | 1400*1190*1935 | |
in | 25.6*16.9*21.7 | 29.5*19.7*23.6 | 40*22.9*21.2 | 44*38*65.3 | 46.5*38*65.3 | 55*47*76 | ||
Weight(c/w backup tong) | kg | 158 | 220 | 840 | 840 | 860 | 1180 | |
lb | 348 | 485 | 1840 | 1840 | 1910 | 2600 | ||
