6M Concrete Paver RP603L Asphalt Road Paver Machine
- Category: >>>
- Supplier: Newindu Construction Engineering (shanghai) Co. Ltd.Newindu Ltd.
Share on (1601316622519):
Product Overview
Description
Products Description
* The control mode is upgraded to mature CAN communication, intelligent paving management function allowing real-time monitoring and automatic fault diagnosis of the whole vehicle.
* The walking control utilizes the technology of constant speed automatic control to avoid the paving speed affected by load.
* Ultrasonic automatic control technology is adopted to control the material level. The material level can be controlled stably and the auger speed can be adjusted continuously.
* Digital automatic leveling technology ensures high evenness, filling the requirements of high-grade road construction.
* The control console can slide freely in the width direction of direction for easy operation.
* Providing operator with an accessible view of the critical areas such as hoppers, chute and working devices.
* The optional rotatable seat provides the operator with a clear view of the key areas such as the hopper, the chute and the
working device.
* Electric heating adopts high-power generator, and optimized heating bar structure and wiring mode, faster heating speed, higher reliability.
* The walking control utilizes the technology of constant speed automatic control to avoid the paving speed affected by load.
* Ultrasonic automatic control technology is adopted to control the material level. The material level can be controlled stably and the auger speed can be adjusted continuously.
* Digital automatic leveling technology ensures high evenness, filling the requirements of high-grade road construction.
* The control console can slide freely in the width direction of direction for easy operation.
* Providing operator with an accessible view of the critical areas such as hoppers, chute and working devices.
* The optional rotatable seat provides the operator with a clear view of the key areas such as the hopper, the chute and the
working device.
* Electric heating adopts high-power generator, and optimized heating bar structure and wiring mode, faster heating speed, higher reliability.
Specification
Basic Pave Width | m | 2.5~4.75 |
Maximum Pave Width | m | 6 |
Maximum Layer Thickness | mm | 350 |
Maximum Paving Speed | m/min | 20 |
Maximum Travel Speed | km/h | 3 |
Hopper Capacity | t | 14 |
Maximum Laydown Rate | t/h | 400 |
Engine and Type | - | QSB6.7-C170 |
Rated Power | kW/rpm | 129/2200 |
Shipping Dimension (LxWxH) | mm | 6680*2500*3180 |
Shipping Weight | t | 18.5 |
