Advanced Water ink Balance Intermittent Varnish Flexo Unit Label Machine 4 Color Offset Printing Machine
- Category: >>>
- Supplier: Shenzhen Huada Huahui Machinery Co. Ltd.Shenzhen Ltd.
Share on (1601317838502):
Product Overview
Description
Product Overview
DJKJM (HDPS-350)
Master control system;
Ink blending system;
Ingenious combination of constant tension correction system and suspended paper return system;
Features:
1.Adopted import servo system, controlled by flexible movement system.
2.Ink supply system controlled by computer, ink transferring is stable and precise.
3.Maximum printing area of intermittent type is 305mm*280mm.
4.High speed and precise alignment, keep precise alignment when accelerating and decelerating, ensure stable performance.
5.With low back clearance and high precision gear, running smoothly at high speed, low noise.
6.Each lamp holder of UV drier can be automatically switch power, achieves the result of low temperature paper no deformation and ink completely dry.
7.Equipped with electronic eye sensor, to ensure the high quality of the secondary overprint and reduce material wastes.
8.Adjusting the settings of overprinting by man-machine interface directly, the operation is more simple and accurate.
9.Printing tension can be adjusted freely according to the needs of different printed materials.
10.Adopted isolated type of power supply mode, saving more power under the same condition.
11.Introduced the foreign advanced shaftles printing control technology.
12.Can be equipped with flexo UV varnishing unit and magnetic rotary die-cutting unit, widely used in food industry, cosmeticindustry, pharmaceutical industry, electronics industry, mobile phone sticker industry, hardware industry, gifts and toys industry, etc.
FEATURES AT A GLANCE
High speed and precise alignment, keep precise alignment when accelerating and decelerating, ensure stable performance.
Can be equipped with flexo UV varnishing unit and magnetic rotary die-cutting unit, widely used in food industry,
cosmeticindustry, pharmaceutical industry, electronics industry, mobile phone sticker industry, hardware industry, gifts and toys
industry, etc.
cosmeticindustry, pharmaceutical industry, electronics industry, mobile phone sticker industry, hardware industry, gifts and toys
industry, etc.
Ink supply system controlled by computer, ink transferring is stable and precise.
Maximum printing area of intermittent type is 305mm*280mm
Ink supply system controlled by computer
The label does not deform and the ink is completely dry. Perfect printing
SPECIFICATION:
Products Name | HD-350PS Full Automatic Rotary Label Printing Machine |
Model | HDPS-350 |
Maximun material width | 350MM |
Maximum printing width | Operating weight |
Printing length range | 175-350MM |
Printing thickness | 0.1-0.3MM |
Machine speed | 50-200rp(50M/min) |
Maximun unwinding diameter | 700MM |
Maxmum winding diameter | 700MM |
Air pressure | 7KG/CM² |
Host power | 30KW/6 colors(Not including UV) |
UV system power | 4.8KW/color |
Power Supply | 3phases 380v |
Outline size | 9500*1700*1600MM |
Machine weight | About 13tonne/6colors |
Company Profile
Shenzhen Huada Huahui Machinery Co., Ltd was established in 1988, rename from the Huahui Machinery Factory.
It is a subsidiary of Hanyan Group, professionally specialized in the research and development, production and sales of high-quality label rotary printing machines R&D, set design, manufacturing, installation and commissioning as one. Huada has its own processing and production center,equipped with CNC lathes, CNC milling machines, high-precision grinding machines, detection projectors and AgieCharmilles wire cutting machine, strictly control the precision of each process and parts, to ensure the high quality of machinery and equipment and printing precision. Huada has absorbed with a large number of professionals and has a number of invention patents. At the same time, we introduce foreign advanced shaftless printing control technology, in the original technology of continuous innovation, so that the product more sophisticated, more stable, more convenient operation.
The main products of the company are Intermittent Rotary Label Printing Machine, NC Oblique Type Adhesive
Label Printing Machine, High-speed Single-seat Die-cutting Machine, Magnetic Circular Knife Die-cutting Machine, Quality Inspection Machine, Plate Copying Machine, Slitting Machine, Paper Feeder and Rewinding Machine and other supporting equipment.Products are not only sold well in the country, but also exported to India, Brazil,
Malaysia, Indonesia, Turkey and other countries and regions, and won the praise of many customers. For 16 years, Huada has been adhere to the "Strive to excellent, stand higher and aim far, pragmatic and innovation, integrity and dedication" concept, adhering to the "quality first, customer supreme, service for this" values, is committed to enterprise development strategy, strengthen enterprise management, the development of enterprise culture, encourage technological innovation, improve the quality of customer service, strive to become a big international first-class high-tech enterprises.Huada is your ideal choice, looking forward to sincere cooperation with colleagues from all walks of life to create a brilliant future.
The main products of the company are Intermittent Rotary Label Printing Machine, NC Oblique Type Adhesive
Label Printing Machine, High-speed Single-seat Die-cutting Machine, Magnetic Circular Knife Die-cutting Machine, Quality Inspection Machine, Plate Copying Machine, Slitting Machine, Paper Feeder and Rewinding Machine and other supporting equipment.Products are not only sold well in the country, but also exported to India, Brazil,
Malaysia, Indonesia, Turkey and other countries and regions, and won the praise of many customers. For 16 years, Huada has been adhere to the "Strive to excellent, stand higher and aim far, pragmatic and innovation, integrity and dedication" concept, adhering to the "quality first, customer supreme, service for this" values, is committed to enterprise development strategy, strengthen enterprise management, the development of enterprise culture, encourage technological innovation, improve the quality of customer service, strive to become a big international first-class high-tech enterprises.Huada is your ideal choice, looking forward to sincere cooperation with colleagues from all walks of life to create a brilliant future.
Exhibition
PRODUCT CONFIGURATION
6colors available
Ink blending system
Flexo UV varnishing unit and magnetic rotary die-cutting unit available
SALES AND SERVICE NETWORK
Successful Project
Project in China
Project in India
Project in Türkiye
SIMILAR PRODUCTS IN OUR FACTORY
HD-300A(6-C)
Full Automatic Rotary Label Printing Machine-6 Colors
HD-320A(4-C)
Full Automatic Rotary Label Printing Machine-4 Colors
HD-300A(7-C)
Full Automatic Rotary Label Printing Machine-7 Colors
PACKING
FAQ
1.Q:How about the after service?
A: We have a strong team, special for after service, we can arrange engineers to do service for you.
2.Q: Are you factory or trading company?
A: We are a factory in this field nearly 20 years.
3. Q: Where is your factory located? How can I visit?
A: Our factry is located in Shenzhen City, near to the Baoan Shenzhen airpot, you can fly to Shenzhen directly, we can arrange to pick you up.
4. Q: How does your factory do the quality control?
A:Quality is prrority, we always attach gerat importance to quality controlling from the beginning.
5. Q:Why choose Wanjie Machinery?
A: We are one of leader in this filed in China. Our quality productes and service have enabled use to expend our market from China to more than 30 countries.
A: We have a strong team, special for after service, we can arrange engineers to do service for you.
2.Q: Are you factory or trading company?
A: We are a factory in this field nearly 20 years.
3. Q: Where is your factory located? How can I visit?
A: Our factry is located in Shenzhen City, near to the Baoan Shenzhen airpot, you can fly to Shenzhen directly, we can arrange to pick you up.
4. Q: How does your factory do the quality control?
A:Quality is prrority, we always attach gerat importance to quality controlling from the beginning.
5. Q:Why choose Wanjie Machinery?
A: We are one of leader in this filed in China. Our quality productes and service have enabled use to expend our market from China to more than 30 countries.
