Factory Price S Valve Trailer Concrete Pump HBT9028CH 5S
- Category: >>>
- Supplier: Evangel Industrial (Shanghai) Co. Ltd.Evangel Ltd.
Share on (1601323676528):
Product Overview
Description
Brand New Diesel Trailer Concrete Pump HBT9028CH-5S for Sale
July Li
Email: july(@)evangelchina.com
Online Chat: WhatsApp /Wechat/ Mobile: +86 13122691510
Product Description
ADVANCED HYDRAULIC SYSTEM
Differential pressure controlled, bi-directional hydraulic system
High flow, high efficiency valve system
Automatically retracted pistons
EFFICIENT PUMPING SYSTEM
High-efficiency pump technology
High power mixing motor
Large bore reversing cylinder
New-lype hopper
WEAR-RESISTING TECHNOLOGY
G5 improved wearing part adopt
Sino-Germany high-techmalerials and advanced technology to greatly improve the productperormance.
Dimensions
| Model | HBT9028CH-5S | ||
| Max,Delivery Pressure (theoretical)(Mpa) | Low Pressure | 19 | |
| High Pressure | 28 | ||
| Max, Concrete Output (theoretical)(m/h) | Low Pressure | 95 | |
| High Pressure | 70 | ||
| Motor Rated Power (kW/rpm) | 2×180/2200 | ||
| Delivery Cylinder Bore (mm) x Strok(mm) | 200×2100 | ||
| Hopper Capacity (m') × Feeding Height (mm) | 0.7×1420 | ||
| Dimension (L×W×H)(mm) | 7820×2300×2750 | ||
| Gross Weight (kg) | 11910 | ||
| Max, Aggregate Size (mm) | Delivery Pipe | 150mm | 50 |
| 120 mm | 40 | ||
| Type | S-Valve | ||
| Slump of Concrete (mm) | 100-230 | ||
