TechnicalSpecification | MERC-1100W-P | MERC-1300W-P | ||||||
Input | ||||||||
Rated Input DC Power | 1100W | 1300W | ||||||
Max. input voltage | 125V | |||||||
MPPT operating voltage range | 12.5-105 V | |||||||
Max. short-circuit current (Isc) | 20 A | |||||||
Max. efficiency | 99.5 % | |||||||
Weighted efficiency | 99.0 % | |||||||
Overvoltage category | II | |||||||
Output | ||||||||
Max. output voltage | 80 V | |||||||
Max. output current | 22 A | |||||||
Output bypass | Yes | |||||||
Shutdown output voltage per optimizer³ | 1 V | |||||||
Standard Compliance | ||||||||
Safety | IEC62109-1 (class II safety) | |||||||
RoHS | Yes | |||||||
General Data | ||||||||
Dimension (W x H x D) | 149 mm x 104 mm x 49 mm (5.9 in. x 4.1 in. x 2.0 in.) | |||||||
Weight (including cables) | 1.05 kg (2.2 lb.) | |||||||
Installation part(optional) | PV Module Frame Plate, T-shaped Bolt | |||||||
Input connector | MC4 | |||||||
Output connector | MC4 | |||||||
Input wire length | 0.1 m (short input cable version)4 | |||||||
Output wire length | 0.1 m (+), 5.1 m (–) (short input cable version)4 | |||||||
Operating temperature / humidity range | –40°C to +85°C 5 / 0%–100% RH | |||||||
Degree ofprotection | IP68 | |||||||
Compatible product | SUN2000-12/15/17/20KTL-M2 SUN2000-12/15/17/20/23/25KTL-M5 SUN2000-30/36/40KTL-M3 SUN2000-50KTL-M3 |
