Water Fan Coil System Floor Standing Hydronic Fancoil Fan Coil Units For Household Cooling heating
- Category: >>>
- Supplier: Guangdong Europe Mango New Energy Technology Co. Ltd.Guangdong Ltd.
Share on (1601354466282):
Product Overview
Description
Model | FFP-34 | FFP-51 | FFP-68 | FFP-85 | |||||
Cooling Capacity 7°C chilled water | kW | 2.2 | 3.2 | 3.95 | 4.8 | ||||
Heating Capacity 60°C hot water | kW | 3.3 | 4.8 | 5.92 | 7.15 | ||||
Advise Area | m2 | 10 | 15 | 20 | 25 | ||||
Advise Flow | m2/h | 350 | 560 | 700 | 875 | ||||
Noise | dBa | 35 | 37 | 39 | 41 | ||||
Water Resistance | kPa | 30 | 30 | 30 | 40 | ||||
Power input | W | 31 | 40 | 55 | 70 | ||||
Motor NO. | 1 | ||||||||
Fan NO. | 1 | 2 | |||||||
Condenser length | mm | 400 | 550 | 650 | 700 | ||||
Condenser hight | mm | 210 | |||||||
Conderser thinhkness | mm | 39 | |||||||
Packing Dimension | mm | 770*240*590 | 920*240*590 | 1020*240*590 | 1070*240*590 | ||||
Weight | kg | 11 | 15 | 17.2 | 17.9 | ||||
Model | FFP-102 | FFP-136 | FFP-170 | FFP-204 | ||||
Cooling Capacity 7°C chilled water | kW | 5.8 | 7.4 | 9.3 | 11 | |||
Heating Capacity 60°C hot water | kW | 8.7 | 11 | 13.95 | 16.4 | |||
Advise Area | m2 | 30 | 40 | 50 | 60 | |||
Advise Flow | m2/h | 1045 | 1410 | 1790 | 2050 | |||
Noise | dBa | 44 | 45 | 47 | 49 | |||
Water Resistance | kPa | 40 | 40 | 42 | 43 | |||
Power input | W | 83 | 110 | 145 | 180 | |||
Motor NO. | 1 | 2 | ||||||
Fan NO. | 2 | 3 | 4 | |||||
Condenser length | mm | 900 | 1050 | 1300 | 1500 | |||
Condenser hight | mm | 210 | ||||||
Conderser thinhkness | mm | 39 | ||||||
Packing Dimension | mm | 1270*240*590 | 1420*240*590 | 1670*240*590 | 1870*240*590 | |||
Weight | kg | 20.6 | 22.5 | 25.8 | 29 | |||
