XE55GA Strengthen 5.5Ton Crawler Excavators Mini Small Digger With Imported Engine
- Category: >>>
- Supplier: Richmchn Machinery Engineering (Shanghai) Co. Ltd.Richmchn Ltd.
Share on (1601367588261):
Product Overview
Description
XE55GA Strengthen 5.5Ton Crawler Excavators Mini Small Digger With Imported Engine
Contact Way
Durant Zhang - Sales Manager
Tel: +86-18721666299
Whatsapp/Wechat/Mobile: +86-18721666299
Email: durant@richmchn.com
Whatsapp/Wechat/Mobile: +86-18721666299
Email: durant@richmchn.com
Product Overview
5.5 Ton Crawler Excavator XE55GA
* Operating weight: 5.5 Ton
* Operating weight: 5.5 Ton
* Bucket Capacity:0.23m³
High Performance and Highlights
More energy-saving and environmentally friendly:
High Performance and Highlights
More energy-saving and environmentally friendly:
1. It adopts a mechanical fuel injection engine that meets the National III
emission standards, which is powerful, energy-saving, environmentally friendly, highly reliable and has excellent performance.
2. The key hydraulic parts adopt the latest technological achievements, with low energy consumption, fast response speed, precise control, small impact, and can maintain strong excavation capabilities and excellent operating efficiency. The engine and hydraulic system power are perfectly matched to ensure that the engine works in the optimal fuel consumption area, improve fuel utilization, and save use costs. The new hydraulic system provides sufficient flow for each working device and has high working efficiency.
More efficient returns:
1. The tail turning radius adopts a compact short tail design to ensure that there is no need to worry about the tail hitting
obstacles when working in narrow working conditions. The working device can be deflected, with the left and right deflection angles of 75 and 55 degrees respectively, which can realize compound operation with the upper vehicle rotation. By cooperating with the upper vehicle rotation, excavation parallel to the wall can be achieved in a small space.
2. The new color 7-inch LCD large-screen liquid crystal display is more in line with ergonomic requirements and can realize rapid switching of machine tool modes. The system can provide 8 languages for users to choose from, with complete instrument information display, more automatic control functions, intelligent diagnosis of fault causes, maintenance information prompts, and fuel filling prompts, effectively shortening maintenance time.
More reliable and durable:
1. The cab meets TOPS/ROPS/OPG safety requirements, while ensuring the strength of the cab and improving the driver's field of vision. The standard retractable seat belt improves the driver's operating safety.
2. The parts of the boom and bucket rod with high stress are partially strengthened, and the structure is adjusted to disperse the stress and increase the service life.
3. The boom has built-in working pipelines and wiring harnesses to better protect the working pipelines and wiring harnesses and increase the service life.
4. Multiple machine pipelines can meet the diverse machine tool needs including quick-change devices.
emission standards, which is powerful, energy-saving, environmentally friendly, highly reliable and has excellent performance.
2. The key hydraulic parts adopt the latest technological achievements, with low energy consumption, fast response speed, precise control, small impact, and can maintain strong excavation capabilities and excellent operating efficiency. The engine and hydraulic system power are perfectly matched to ensure that the engine works in the optimal fuel consumption area, improve fuel utilization, and save use costs. The new hydraulic system provides sufficient flow for each working device and has high working efficiency.
More efficient returns:
1. The tail turning radius adopts a compact short tail design to ensure that there is no need to worry about the tail hitting
obstacles when working in narrow working conditions. The working device can be deflected, with the left and right deflection angles of 75 and 55 degrees respectively, which can realize compound operation with the upper vehicle rotation. By cooperating with the upper vehicle rotation, excavation parallel to the wall can be achieved in a small space.
2. The new color 7-inch LCD large-screen liquid crystal display is more in line with ergonomic requirements and can realize rapid switching of machine tool modes. The system can provide 8 languages for users to choose from, with complete instrument information display, more automatic control functions, intelligent diagnosis of fault causes, maintenance information prompts, and fuel filling prompts, effectively shortening maintenance time.
More reliable and durable:
1. The cab meets TOPS/ROPS/OPG safety requirements, while ensuring the strength of the cab and improving the driver's field of vision. The standard retractable seat belt improves the driver's operating safety.
2. The parts of the boom and bucket rod with high stress are partially strengthened, and the structure is adjusted to disperse the stress and increase the service life.
3. The boom has built-in working pipelines and wiring harnesses to better protect the working pipelines and wiring harnesses and increase the service life.
4. Multiple machine pipelines can meet the diverse machine tool needs including quick-change devices.
Product Parameters
Description | Unit | Parameter value | ||||
Operating weight | Kg | 5700 | ||||
Bucket capacity | m³ | 0.2 | ||||
Engine | Model | / | 4TNV94L-BVXG | |||
Style | Direct injection | / | √ | |||
Four strokes | / | √ | ||||
Water cooling | / | √ | ||||
Turbo-charging | / | × | ||||
No. of cylinders | / | 4 | ||||
Output power | kw/rpm | 36.2/2100 | ||||
torque/speed | N.m | 193.2-210.6/1260 | ||||
Displacement | L | 3.054 | ||||
Main performance | Travel speed(H/L) | km/h | 4.2/2.2 | |||
Rotating speed | r/min | 10 | ||||
Gradeability | ° | 35 | ||||
Ground pressure | kPa | 31 | ||||
Bucket digging force | kN | 48.3 | ||||
Arm crowd force | kN | 32.5 | ||||
Maximum traction | kN | 50.5 | ||||
Hydraulic system | Main pump | / | / | |||
Rated flow of main pump | L/min | 149.1 | ||||
Pressure of prime valve | MPa | 24 | ||||
Pressure of travel system | MPa | 24 | ||||
Pressure of swing system | MPa | 21 | ||||
Pressure of pilot system | MPa | 3.5 | ||||
Oil Capacity | Fuel tank capacity | L | 110 | |||
Hydraulic tank capacity | L | 77 | ||||
Engine oil capacity | L | 10 | ||||
Appearance size | Overall length | mm | 5860 | |||
Overall width | mm | 1950 | ||||
Overall height | mm | 2585 | ||||
Width of platform | mm | 1780 | ||||
Length of crawler | mm | 1920 | ||||
Overall width of chassis | mm | 400 | ||||
Width of crawler | mm | 1990 | ||||
Crawler gauge | mm | 1500 | ||||
Clearance under counterweight | mm | 700 | ||||
Min. ground clearance | mm | 385 | ||||
Dozer blade width/height | mm | 1920/340 | ||||
Working scope | Max. digging height | mm | 5630 | |||
Max. dumping height | mm | 3945 | ||||
Max. digging depth | mm | 3830 | ||||
Max. vertical wall digging depth | mm | 2680 | ||||
Max. digging reach | mm | 6130 | ||||
Min. swing radius | mm | 2460 | ||||
Min. tail swing radius | mm | 1670 | ||||
Max.dozer blade hoist height | mm | 390 | ||||
Max. dozer blade digging depth | mm | 560 | ||||
Standard Congratulation | Boom Length | mm | 3000 | |||
Arm Length | mm | 1600 | ||||
Bucket Capacity | m³ | 0.2 | ||||
