Siglent SDG805,5MHz Arbitrary Signal Generator

Product Overview

Description



Frequency Specification	Model	SDG805	SDG810	SDG830
	Waveform	Sine, Square, Ramp, Pulse, Gaussian Noise. 46 built-in arbitrary waveforms(include DC)
	Output channels	1 Channel
	Sine	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 30MHz
	Square	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 10MHz
	Pulse	500μHz ~ 5MHz
	Ramp/Triangular	1μHz ~ 300kHz
	Gaussian white noise	>5MHz (-3dB)	>10MHz (-3dB)	>30MHz (-3dB)
	Arbitrary	1μHz ~ 5MHz
	Resolution	1μHz
	Accuracy	Within 90days ±50ppm within 1 year ±100ppm
	Temperature coefficient	<5ppm/°C
Sine Wave	Harmonic Distortion	DC~1MHz         <-60dBc
		1MHz~10MHz   <-55dBc
		10MHz~30MHz <-50dBc
	Total harmonic waveform distortion	DC~20kHz 1Vpp<0.2%
	Spurious signal(non-harmonic)	DC~1MHz         <-70dBc
		1MHz~10MHz   <-60dBc
		10MHz~30MHz <-55dBc
	Phase noise	10kHz Offset,–108dBc/Hz(typical value)
Square Wave	Rise/fall time	<24ns(10% ~ 90%)
	Overshoot	<5%(typical,1kHz,1Vpp)
	Duty Cycle	20%~80%
	Asymmetric	1% of period+20ns(typical,1kHz,1Vpp)
	Jitter	500ps + 0.001% of period
Ramp/Triangle Wave	Linearity	<0.1% of Vpp(typical,1kHz,1Vpp,100% symmetric)
	Symmetry	0%~100%
Pulse Wave	Pulse width	16ns, Min. 1ns resolution
	Rise/Fall time	20ns~1.6ks (10% ~ 90%,typical)
	Duty Cycle	0.1%Resolution
	Overshoot	<5%
	Jitter(pk-pk)	500ps + 0.001% of period
Arbitrary Wave	Waveform length	16k points
	Vertical resolution	14bits
	Sample rate	125MSa/s
	Min. Rise/Fall time	8ns(typical)
	Jitter(pk-pk)	8ns(typical)
	Storage in non-volatile RAM memory	10 waveforms (10 in total)
Output Specification	Amplitude	2mVpp~10Vpp(50Ω,≤10MHz) 2mVpp~5Vpp(50Ω,>10MHz)
	Vertical accuracy	±(1mVpp +0.3dB of setting value)   (100 kHz sine)
	Amplitude flatness	±0.3 dB (compared to 100 kHz sine,5Vpp)
	Impedance	50Ω
	Protection	short-circuit protection
DC Offset	Range(DC)	±5V(50Ω) ±10V(High-Z)
	Offset accuracy	±(|setting offset value|*1%+3mV)
AM Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	Sine, Square, Ramp, Noise, Arbitrary (2mHz ~ 20kHz)
	Modulation depth	0% ~ 120%
DSB-AM Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	Sine, Square, Ramp, Noise, Arbitrary (2mHz ~ 20kHz)
	Modulation depth	0% ~ 120%
FM Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	Sine, Square, Ramp, Noise, Arbitrary (2mHz ~ 20kHz)
	Frequency deviation	0 ~0.5*bandwidth 1mHz resolution
PM Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	Sine, Square, Ramp, Noise, Arbitrary (2mHz ~ 20kHz)
	Phase Deviation	0~360° ,0.1°Resolution
FSK Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	50% duty-cycle square waveform(2mHz~50kHz)
ASK Modulation	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Modulation waveform	50% duty-cycle square waveform(2mHz~50kHz)
PWM Modulation	Frequency	500μHz~20kHz
	Modulation waveform	Sine, Square, Ramp, Arbitrary(except DC)
Sweep	Carrier	Sine, Square, Ramp, Arbitrary(except DC)
	Type	linear/logarithmic
	Direction	Up/down
	Sweep time	1ms~500s
	Trigger source	Manual, external, internal
Burst	Waveform	Sine, Square, Ramp, Pulse, Arbitrary(except DC)
	Type	Count(1~50,000 periods),infinite, Gated
	Start/Stop phrase	0°~360°
	Internal period	1μs~500s
	Gated source	External trigger
	Trigger source	Manual, External or Internal
Trigger Input	Input Level	TTL compatible
	Slope	Up or down
	Pulse width	>100ns
	Input impedance	>5kΩ,DC coupling
SYNC Output	Voltage level	TTL compatible
	Pulse width	>50ns
	Output impedance	50Ω(typical)
	Max. frequency	2MHz
Interface	Standard Interface	USB Device, USB Host
Display type		3.5inch’TFT-LCD
Dimension		229(W)mm*105(H)mm*281(D)mm
Weight		N.W: 2.6Kg; G.W: 3.4Kg
