STA 1430C 1260C ceramic fiber blankets(96/m3 128kg/m3) with best price
Product Description
STA ceramic fiber blankets is made of special ceramic long-fiber that is produced by the melting of very pure raw materials in double surface meeding process with out binders and with good stability in a large range of temperature. The process of double surface needing increase interweaving and tensile strength .
Features
1.Good insulation of ceramic fiber blankets 2.Good obstructing voice and mechanism strength 3.Low shrinkage 4.Good springiness for fibers 5.Convenient producing and installing 6.Excellent chemistry quality 7.Resistance to burning 8.Low thermal conductivity 9.Low thermal capacity
the specification of ceramic fiber blanket
Item
Standard
High Pure
High Aluminum
Alu-Zirconium
Zirconium
Classification Temp (°C)
1260
1260
1360
1360
1430
Working Temp (°C)
≤1050
≤1100
≤1200
≤1200
≤1350
Color
Pure White
Pure White
Pure White
Pure White
Pure White
Bulk Density (Kg/m3)
64-160
64-160
96-160
96-160
96-160
Permanent Linear Shrinkage(%)
1000°CX24h≤3
1100°CX24h≤3
1200°CX24h≤3
1350°CX24h≤ 3
Thermal Conductivity (w/m.k)(128Kg/m3)
0.09(400°C)
0.16(800°C)
0.09(400°C)
0.16(800°C)
0.12(600°C)
0.20(1000°C)
0.12(600°C)
0.20(1000°C)
0.16(800°C)
0.20(1000°C)
Tensile Strength (Mpa)(128Kg/m3)
0.08-0.12
0.08-0.12
0.08-0.12
0.08-0.12
0.08-0.12
Chemical Composition(%)
AL2O3
45-46
47-49
52-55
45-46
39-40
AL2O3+SIO2
97
99
99
-
-
AL2O3+SIO2+ZrO2
-
-
-
99
99
ZrO2
-
-
-
5-7
15-17
Fe2O3
≤1.0
≤0.2
≤0.2
≤0.2
≤0.2
Na2O+K2O
≤0.5
≤0.2
≤0.2
≤0.2
≤0.2
Standard Size
7200 x 600 x 25mm; 3600 x 600 x 50mm
7200 x 610 x 25mm; 3600 x 610 x 50mm
Typical application of ceramic fiber blanket
Wall lining and back lining of industrial furnaces;
Boiler insulations;
Heat treatment temperature control;
Glass furnace crown insulation;
Furnace door seals;
Duct linings and Pipe insulations;
Insulation of the shell of precision casting;
Insulation of the roller of heating furnaces;
Insulation of petrochemical heating furnaces;
Insulating materials of high-temperature equipment;
Fire protection;
Materials for hot filtration;
Steam turbine and nuclear insulation
Packaging & Shipping
Our Services
High puriy material make sure high max working temperature, Tight tolerance make sure the right installation. Large quantity ceramic fiber blanket in stock ensured fast delivery Large capacity reduce ceramic fiber blanket prices
best service after sales
Company Information
STA universe group is founded in 2001,dedicating to innovation ang creating a world famous brand.And provide verious products for customers .
