Float Switch Submersible Sewage Pump

Product Overview

Description

Flaot Switch's operation voltage is 220vac, and current can be up to 15A. Applies to branch water,sewage,aid-base solution and oil.

• Microswitch: 10(8)A 250V~10(4)A 380V


• Switch currency:   ≥50 000switch workings tested by VDE specialisation


• Protective connection:  T 70U


• Protection:  waterproof


• Max.temperature:   70°C


• Working pressure:   max.1bar


• Circuitbreaking capacity: Directly KW with 250V


•

  Standard Cable Length: 5m ~ 100mm  or Accorrding to customer’s request




•

  Float: Polypropylene




• Cable:polypropylene Jacket


• Counter Weight: Polypropylene Sealed Housing


• Cable Material: HO7RN- F3x0.75mm2 , PVC (3x0. 5mm2,3x0.75mm2, 3x1.0mm2)


•
