Product Overview

Description

 Elevator Guide Rails and Elevator Parts/China Elevator Guide Rail



1.Details: T45/A:45*45* 5mm T50/A: 50*50*5mm T70/B: 70*50*15.88mm T70-1/B: 70*65*9mm T75-3/B: 75*62*10mm  T78/B: 78*56*10mm T82/B: 82.5*68.25*9mm T89/B: 89*62*15.88mm  T90/B: 90*75*16mm                       T114/B: 114*89*16mm             T127-1/B: 127*88.9*15.88mm

T127-2/B: 127*88.9*15.88mm      T140-1/B: 140*108*19mm         T140-2/B: 140*102*28.6mm  T140-3/B: 140*127*31.75mm       TK3:75*55*10mm     TK3A:75*55*10mm      TK5:87*60*16.4mm TK5A:78*60*16.4mm

2. We passed the ISO9001:2000 Certificate and produce standard ISO7465:2001

3. Material:Q235A Q235B



4. Package: T45/A, T50/A, TK3, TK5, TK3A, TK5A is 50 pcs/bundle, T70-1/B, T70/B, T75-3/B, T78/B, T82/B, T89/B, T90/B, T114/B, T127-1/B, T127-2/B is 20 pcs/bundle. We use sheath protect the end of the guide rail and iron plate also protect the guide rail.and the coating with plastic cloth.

5. T-Clips Forged rigid guide rail clamping system. Recommended for application where guide rail stack movement is not expected. These clips come complete with threaded shank and nut. T-Clips are available both in burnished and zinc-coated finishing.

T1(M10 , 32mm) use for T45/A, T50/A         T2(M12, 39mm) use for T70-1/B, T75-3/B T78/B, T82/B T3(M14, 45mm) use for T89/B, T90/B          T4(M16, 50mm) use for T114/B, T127-1/B, T127-2/B    T5(M18, 55mm) use for T140-1/B, T140-2/B



 6. We also can produce non-standard guide rail follow customer's requirements.
