plasma cutter cut 60 And Consumables

Product Overview

Description

                     plasma cutter cut 60 And Consumables



Name: plasma cutter cut 60 And Consumables

Model: CUT-40/CUT-50/CUT-60/CUT-100.

Suitable Base Materials:  Aluminium, Al-Mn alloy, Al-Mg alloy, Carbon steel, Stainless steel, Low-alloy steel

automobile manufacturing, machinery manufacturing .





Plasma cutting machine Product Features :

1. High cutting speed, the cutting speed can be several times of torch cutting, low operation cost

     plasma cutter cut 60 And Consumables

2. Narrow cutting gas, smooth cutting surface, small distortion, no need to reprocess

    plasma cutter cut 60 And Consumables

3. Easy to cut thick plate, fast, economic and practical.

    plasma cutter cut 60 And Consumables

4. Widely use in cutting simple steel, stainless steel, aluminium, titanium, nickel combined metal, cast iron and other metals

technical specification:

Inverter DC Air Plasma Cutter
Model	CUT-40	CUT-60
Type	MOSFET
Rated input voltage (V)	single phase AC220 ±15%	three phase AC380 ±15%
Rated frequency (Hz)	50/60
Rated input capacity (KVA)	6.6	7.9
Rated input current (A)	30	12
No-load voltage (V)	230	260
Output current (A)	20-40	20-60
Rated working voltage (V)	96	104
Duty cycle (%)	60	60
No-load loss (W)	100	100
Efficiency (%)	80	80
Power factor	0.73	0.73
Net weight (KG)	8.7	16.6
Gross weight (KG)	12	21
Dimension of machine (mm)	400×163×290	500×210×370
Dimension of packing (mm)	450×235×390	560×270×460
Method of arc start	contact	contact
Cutting thickness (mm)	steel: 0.3-16	steel: 1-25
Optimum thickness of work piece (mm)	steel: 0.3-8	steel: 1-15
	aluminum/copper: 0.3-4	aluminum/copper: 1-7
including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, gas hose×0.6meter, hose hoop×2pcs, cutting torch×1pcs



Plasma Cutting Machine Details:



01.  100% seamless, full-chip technology of the control panel,greatly increase the reliability of plasma cutting machine , at the same time Saip exclusive using over-current protection system on the control panel , prevent large current shock, prevent the plasma cutting machine secondary damage, even Fried tube.

      plasma cutter with Complete accessories: air cooling cutting torch, earth clamp, compressed air regulator, etc.

02.  Saip is the only stick with the most advanced   of the amorphous structure transformer  200G models in China, the machine efficiency is over 32%, compared to "ferrite" is extended more than twice the life.



Main Components of Different :

About ours:

FAQ:

1. We offer 2 year warranty, plasma cutter any non operational failure, 1 year free replacement, two years free maintenance.



2. We provide technical support for 5 years,  you can feel free to contact us to solve problem, and we provide plasma cutter parts supply support.



3. We provide 48 hours delivery for small order, bulk purchases of delivery need to be negotiated.
