Feature
*Exquisite design with precise dimension and craftsmanship;
*Toughened glass front door with silk-screened flower pattern,door border and steel rear door;
*Blue Zinc Mounting Profiles,free of static,;
*Adjustable feet and heavy duty castors are available simultaneously;
*Cable entry on the top cover and bottom panel with adjustable sizes;
*Optional installation of plinth to enable cabinets fixation,under-base cable entry/ventilation;
*Efficient and reliable cabinet connection by baying kit;
*Removable side panels for easy maintenance;
*Around 1/3 assembled original volume when flat pack.
Surface finish: degreasing, pickling, phosphating, electrostatic plastic spraying ;
Degree of Protection: IP20
| No. | Component Name | Quantity | Unit | Material | Surface Finish | Remark |
| 1 | Mounting profile | 4 | pc | SPCC cold rolled steel T1.2 | Powder Coated | --- |
| 2 | Mounting angle | 4 | pc | SPCC cold rolled steel T1.0 | Powder Coated | |
| 3 | Frame | 1 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
| 4 | Small round lock | 1 | pc | --- | Nickel Coatd | --- |
| 5 | Toughened glass front door | 1 | pc | Tempered glass/SPCC T1.0 | Powder Coated | --- |
| 6 | Side Panel | 2 | pc | SPCC cold rolled steel T1.0 | Powder Coated | Removable steel door |
| 7 | M6 Philip-head screw | 10 | pc | Steel | Color Zinc Coated | 20pcs for over 12U |
| 8 | M6 square nut | 10 | pc | Steel | Color Zinc Coated | 20pcs for over 12U |
| Model No. | Capacity (U) | Width (mm) | depth (mm) | Volume (CMB) |
| NWA.6304 | 4U | 600 | 300 | 0.0536 |
| NWA.6404 | 440 | 0.0770 | ||
| NWA.6504 | 500 | 0.0870 | ||
| NWA.6604 | 600 | 0.1038 | ||
| NWA.6306 | 6U | 600 | 300 | 0.0734 |
| NWA.6406 | 440 | 0.1055 | ||
| NWA.6506 | 500 | 0.1193 | ||
| NWA.6606 | 600 | 0.1422 | ||
| NWA.6309 | 9U | 600 | 300 | 0.0992 |
| NWA.6409 | 440 | 0.1426 | ||
| NWA.6509 | 500 | 0.1612 | ||
| NWA.6609 | 600 | 0.1922 | ||
| NWA.6312 | 12U | 600 | 300 | 0.1210 |
| NWA.6412 | 440 | 0.1740 | ||
| NWA.6512 | 500 | 0.1967 | ||
| NWA.6612 | 600 | 0.2345 | ||
| NWA.6315 | 15U | 600 | 300 | 0.1627 |
| NWA.6415 | 440 | 0.2339 | ||
| NWA.6515 | 500 | 0.2644 | ||
| NWA.6615 | 600 | 0.3152 | ||
| NWA.6318 | 18U | 600 | 300 | 0.1895 |
| NWA.6418 | 440 | 0.2724 | ||
| NWA.6518 | 500 | 0.3079 | ||
| NWA.6618 | 600 | 0.3671 |
