Dry Diamond Core Drill Bit

Product Overview

Description

Dry Diamond Core Drill Bit for Cutting Light Concrete, Brick, Block, Stone and other general Building Materials.



For dry cutting very wide range of building materials, such as concrete, brick/block and general building materials.

Our Dry Diamond Core Drill Bit can be very Fast cutting with very long working life.

Our Dry Diamond Core Drill Bit are used high precision steel core tube.

Our Dry Diamond Core Drill Bit are widely used for professional works.



Sizes & Specifications are adjustable according to customers' requests.



Available working length from 50mm, 70mm, 150mm, 300mm to 400mm.

Available diamenter from 14mm to 112mm.

Available all kinds of connection thread, such as 1/2"BSP, 1-1/4"UNC, 5/8", PIXIE, M16,  M22, M27 and ect....

Available all kinds of segment designs and segments types.

Segments height can be adjusted according to customers' requests.

Segments could be welded by laser and braze.





Size & Specifications for reference.



<A>. Germany Type-Dry Diamond Core Drill Bit.







Ø mm	Segment No.	Segment Height.mm	Wrorking Length mm	Connection Thread
32	3	8	70	M16 Female
42	3	8	70	M16 Female
47	3	8	70	M16 Female
52	3	8	70	M16 Female
57	3	8	70	M16 Female
62	3	8	70	M16 Female
68	3	8	70	M16 Female
72	3	8	70	M16 Female
82	4	8	70	M16 Female
92	4	8	70	M16 Female
102	5	8	70	M16 Female
112	5	8	70	M16 Female



 <B>. UK Type:









Ø mm	Segment No.	Wrorking Length mm	Connection Thread
14	Rim	300/400	HEX Shank or 1/2” BSP Female
16	Rim	300/400	HEX Shank or 1/2” BSP Female
18	Rim	300/400	HEX Shank or 1/2” BSP Female
20	Rim	300/400	HEX Shank or 1/2” BSP Female
22	Rim	300/400	HEX Shank or 1/2” BSP Female
24	Rim	300/400	HEX Shank or 1/2” BSP Female
26	Rim	300/400	HEX Shank or 1/2” BSP Female
28	Rim	300/400	HEX Shank or 1/2” BSP Female
30	Rim	300/400	HEX Shank or 1/2” BSP Female
32	Rim	300/400	HEX Shank or 1/2” BSP Female



Details of Products.







 Production of Diamond Core Drill Bits



Production of high precision/quality steel core tubes for diamond core drill bit in own workshop





Packing and Package of our products





 Outlook of Our Factory





 Quality Guaranteed. Certificate of ISO 9001: 2008
