flexible graphite roll,expanded graphite roll sheet

Product Overview

Description

1)Flexible graphite roll is made by flake graphite with high carbon content, which is gone through chemical treatment, expanding under high temperature and then rolling

2)Flexible graphite sheet  has the characteristics of high temperature resistance, corrosion resistance and good elasticity.

3)Flexible graphite sheet sevrve as  the basic material for making all kinds of reinforced graphite sheets, graphite tapes, packing and sealing gaskets. Working temperature-200~650ºC(in air),-200~3000ºC(in non-oxidizing media).

4)



Main Properties
Item		Grade A	Grade B	Grade C	Grade D
Carbon content (%)		99	99	99	98
Sulphur contentPPM		<= 500	<=1000	<=1300	<=1500
Chloride contentPPM		<= 35	<=40	<=45	<=50
Tolerance of density (g/cm3)		± 0.05	± 0.05	± 0.06	± 0.07
Tolerance of thicknessmm		<1± 0.03; 1-1.5± 0.05; >1.5± 0.1
Compressibility(%)		15~55(when density is 1.0g/cm³)
Recovery(%)		>= 10(when density is 1.0g/cm³)
Product Specification
Thickness (mm )		Width(mm)	Length(mm)		Density (g/cm3)
Roll	Sheet	<=1500	<=1500(sheet) 30M,50M,70M,80M(Rolls)		0.7-1.2



5)Pictures:
